NI PXIe-4145 輸入模塊采集器
1.產 品 資 料 介 紹：
中文資料：
NI PXIe-4145 是一款高性能的輸入模塊采集器，它屬于National Instruments（NI）的PXI Express（PXIe）系列。這款模塊具有多種先進的功能和特性，使其在工業自動化、測試與測量等領域有著廣泛的應用。
主要特點
- 四通道源測量單元（SMU）：PXIe-4145是一個四通道的源測量單元，這意味著它可以同時處理四個通道的輸入信號，大大提高了數據采集的效率。
- 四象限運行模式：每個通道都集成了遠程（4線）傳感功能，這有助于實現精確的測量。
- 高采樣速率：PXIe-4145的高采樣速率使得它能夠快速捕獲器件的瞬態特性，從而實現對被測器件（DUT）的快速IV特性分析。
- 同步功能：通過高速序列引擎，用戶可以實現這些SMU之間的同步或與其他儀器（如開關或高速數字測試模塊）的同步。
- SourceAdapt技術：這項技術可以調整PXIe-4145對任何負載的響應，以獲得最佳響應，從而最大程度地提高穩定性和減小瞬態特性。
- 廣泛的應用支持：PXIe-4145適用于各種工業自動化、測試與測量應用，如電子測試、汽車電子、能源管理等。
應用領域
由于其高性能和靈活性，PXIe-4145在多個領域都有廣泛的應用，包括但不限于：
- 電子測試：用于電路板的測試、元件參數的測量等。
- 汽車電子：用于汽車控制系統、電池管理系統等的測試與驗證。
- 能源管理：用于太陽能逆變器、風力發電系統等的性能測試。
總結
總的來說，NI PXIe-4145是一款功能強大、性能卓越的輸入模塊采集器，適用于各種需要高精度、高效率數據采集和測量的應用場景。通過其四通道設計、高采樣速率和同步功能，它能夠滿足復雜系統中對多通道數據采集和精確測量的需求。同時，其廣泛的應用支持和靈活的配置選項也使其成為了工業自動化和測試與測量領域的理想選擇。
英文資料
NI PXIE-4145 is a high-performance input module collector that belongs to the PXI Express (PXIE) series of National Instruments (NI). This module has multiple advanced functions and features, making it widely used in industrial automation, testing and measurement, and other fields.
main features
Four channel source measurement unit (SMU): PXIE-4145 is a four channel source measurement unit, which means it can process input signals from all four channels simultaneously, greatly improving the efficiency of data acquisition.
Four quadrant operation mode: Each channel is integrated with remote (4-wire) sensing function, which helps achieve accurate measurement.
High sampling rate: The high sampling rate of PXIe-4145 enables it to quickly capture the transient characteristics of the device, thereby achieving fast IV characteristic analysis of the device under test (DUT).
Synchronization function: Through a high-speed sequence engine, users can achieve synchronization between these SMUs or with other instruments (such as switches or high-speed digital testing modules).
Source Adapt technology: This technology can adjust the response of PXIe-4145 to any load to obtain the best response, thereby maximizing stability and reducing transient characteristics.
Wide application support: PXIE-4145 is suitable for various industrial automation, testing and measurement applications, such as electronic testing, automotive electronics, energy management, etc.
application area
Due to its high performance and flexibility, PXIE-4145 has a wide range of applications in multiple fields, including but not limited to:
Electronic testing: used for testing circuit boards, measuring component parameters, etc.
Automotive electronics: used for testing and validation of automotive control systems, battery management systems, etc.
Energy management: used for performance testing of solar inverters, wind power generation systems, etc.
summary
Overall, NI PXIE-4145 is a powerful and high-performance input module collector, suitable for various application scenarios that require high-precision and high-efficiency data collection and measurement. Through its four channel design, high sampling rate, and synchronization function, it can meet the needs of multi-channel data acquisition and accurate measurement in complex systems. Meanwhile, its extensive application support and flexible configuration options make it an ideal choice in the fields of industrial automation and testing and measurement.
2.產 品 展 示
3.產 品 展 示
