TOSHIBA 2N3A3620-B電子模塊,2N3A3620-B使用在哪里
安裝接線板之間的電纜
在模塊的接線板上安裝模塊之前，先安裝端子之間的連接電纜
阻礙。TOSHIBA 2N3A3620-B每個輸入/輸出接線板都配有一根短連接電纜，如下圖所示。一套
連接電纜的編號為IC670ACC001?？蛇x21英寸（0.53
儀表）電纜（IC670CBL002）也可用（每個輸入/輸出站只能使用一根更長的電纜）。
下圖顯示了總線接口單元端子之間的基本電纜連接
塊和輸入/輸出端子塊。保護標簽仍在輸入/輸出接線板上，
但已移除標簽角，以允許接觸接線盒電纜接頭。
以相同的方式連接輸入/輸出接線板。接頭采用鍵控，以確保
正確安裝。TOSHIBA 2N3A3620-B電子模塊
Installing the Cables Between Terminal Blocks
Before installing modules on their terminal blocks, install the connecting cable(s) between terminal
blocks. A short connecting cable, illustrated below, is supplied with each I/O Terminal Block. A set
of connecting cables is available as renewal part number IC670ACC001. Optional 21-inch (0.53
meter) cable (IC670CBL002) is also available (only one longer cable can be used per I/O station).
The illustration below shows the basic cable connection between a Bus Interface Unit terminal
block and an I/O Terminal Block. The protective labels are still in place on the I/O Terminal Block,
but the label corners have been removed to permit access to the Terminal Block cable connectors.
Make connections between I/O Terminal Blocks the same way. The connectors are keyed to assure
proper installation.
