HONEYWELL CC-TAON01占位模塊,英文使用說明CC-TAON01
輸出
如果發生復位或局部故障，模塊可以設置實際輸出CC-TAON01
設置為零或保持其最后的值（這需要本地電源）。
零零，保持最后狀態
信道激活信道是否響應命令的模擬和離散
輸出數據和返回警報。如果通道處于非活動狀態，則其輸出為
零如果以前的活動通道重新配置為非活動通道，則任何
仍然可以使用Q數據清除預先存在的報警。
活動-非活動，活動
范圍有兩個預設縮放范圍。
+/–10V（雙極）范圍：量程和工程單位為+/–10000。
0至10V（單極）范圍：量程和工程單位從0至
10,000.
+/–10V+/–10V，
0至10V
以毫伏為單位的低實際電壓范圍將縮放為低工程單位10000–16384至
16 383量程以毫伏為單位的高實際電壓，以高工程單位為單位+10,000 +16,383
工程低工程單位，相當于低跨度值–10,000
HONEYWELL CC-TAON01占位模塊
工程
高的
相當于高跨度值的工程單位。
Local Defaults:
Outputs
If a reset or local failure occurs, the module can set the actual outputs
to zero or hold their last values (this requires local power).
Zero
Zero, Hold Last
State
Channel Active
Whether a channel will respond to commanded analog and discrete
output data and return alarms. If a channel is inactive its output is
zero. If a previously-active channel is reconfigured as inactive, any
pre-existing alarms can still be cleared using Q data.
Active
Inactive, Active
Range
There are two preset scaling ranges.
+/–10V (bipolar) range: span and engineering units from +/–10,000.
0 to 10V (unipolar) range: span and engineering units from 0 to
10,000.
+/– 10V
+/–10V,
0 to 10V
Span Low
Actual voltage in millivolts to be scaled to low engineering units.
–10,000
–16,384 to
16 383
Span High
Actual voltage in millivolts to be scaled to high engineering units.
+10,000
+16,383
Engineering Low
Engineering units equivalent of the low span value.
–10,000
Engineering
High
Engineering units equivalent of the high span value.
