HONEYWELL CC-TDIL01稱重模塊,CC-TDIL01說明書文檔
輔助接線板可用于為屏蔽提供額外的接線端子。
輔助接線板的所有端子內部連接在一起。HONEYWELL CC-TDIL01輔助設備
帶箱式端子的接線板（IC670ACC002）有13個端子；每個可容納一個
AWG#14（平均橫截面2.1mm2）至AWG#22（平均橫截面0.36mm2）電線。
這個
帶屏障端子的輔助接線板（IC670ACC001）有九個端子；每個can
容納一條或兩根AWG#14（平均橫截面2.1mm2）以下的電線。
輸入/輸出端子板端子分配
帶有箱式端子的接線板每個模塊有25個端子。每個可容納一個
AWG#14（平均橫截面積2.1mm2）HONEYWELL CC-TDIL01稱重模塊至AWG#22（平均橫截面積0.36mm2）電線，或兩根
AWG#18以下的電線（平均橫截面0.86mm2）。如果使用外部跳線，則為單線
容量從AWG#14（2.10mm2）降至AWG#16（1.32mm2）。
帶有安全柵端子的輸入/輸出接線板每個模塊有18個端子。每個終端
可容納一條或兩根AWG#14（平均橫截面2.1mm2）以下的電線。
帶連接器的輸入/輸出接線板每個模塊有一個20針公接頭。
所有回路端子彼此共用
An Auxiliary Terminal Block can be used to provide additional wiring terminals for the shields.
Auxiliary Terminal Blocks have all terminals connected together internally. The Auxiliary
Terminal Block with box terminals (IC670ACC002) has 13 terminals; each accommodates one
AWG #14 (avg 2.1mm2 cross section) to AWG #22 (avg 0.36mm2 cross section) wire. The
Auxiliary Terminal Block with barrier terminals (IC670ACC001) has nine terminals; each can
accommodate one or two wires up to AWG #14 (avg 2.1mm2 cross section).
I/O Terminal Block Terminal Assignments
An Terminal Block with Box Terminals has 25 terminals per module. Each accommodates one
AWG #14 (avg 2.1mm2 cross section) to AWG #22 (avg 0.36mm2 cross section) wire, or two
wires up to AWG #18 (avg. 0.86mm2 cross section). If an external jumper is used, single-wire
capacity is reduced from AWG #14 (2.10mm2) to AWG #16 (1.32mm2).
An I/O Terminal Block with Barrier Terminals has 18 terminals per module. Each terminal
can accommodate one or two wires up to AWG #14 (avg 2.1mm2 cross section).
An I/O Terminal Block with Connectors has one 20-pin male connector per module.
All Return terminals are common to each other
