ABSOLUTE MOX12-P3509 B機器人模塊,MOX12-P3509 B說明書文檔
模塊安裝在帶有接線盒端子或輸入/輸出端子的輸入/輸出接線板上
帶屏障端子的接線板，可能需要一個輔助接線板來提供
附加接線端子。MOX12-P3509 B機器人模塊,對于帶線到板連接器的輸入/輸出接線板，
通常首選外部連接點，盡管有輔助接線板可以使用。。
輔助接線板的所有端子內部連接在一起。輔助設備
帶箱式端子的接線板有13個端子，每個端子可容納一個AWG
#14（平均2.1mm2橫截面）至AWG#22（平均0.36mm2橫截面）導線，或兩根以上導線
至AWG#18（平均橫截面0.86mm2）。帶屏障端子的輔助接線板
有九個端子，每個端子可容納一條或兩根導線，最高可達AWG#14（平均值
2.1mm2橫截面）。
下圖顯示了如何使用帶接線盒端子的輔助接線板
用于連接到帶有接線盒端子的輸入/輸出接線板的電源。ABSOLUTE MOX12-P3509 B機器人模塊
Wiring Examples with Auxiliary Terminal Blocks
If the module is installed on an I/O Terminal Block with Box Terminals or an I/O Terminal
Block with Barrier Terminals, an Auxiliary Terminal Block may be required to provide
additional wiring terminals. For the I/O Terminal Block with Wire to Board Connectors,
external connection points are usually be preferred, although an Auxiliary Terminal Block
can be used..
Auxiliary Terminal Blocks have all terminals connected together internally. The Auxiliary
Terminal Block with box terminals has 13 terminals, each of which accommodates one AWG
# 14 (avg 2.1mm2 cross section) to AWG #22 (avg 0.36mm2 cross section) wire, or two wires up
to AWG #18 (avg. 0.86mm2 cross section). The Auxiliary Terminal Block with barrier terminals
has nine terminals, each of which can accommodate one or two wires up to AWG #14 (avg
2.1mm2 cross section).
The following illustration shows how an Auxiliary Terminal Block with Box Terminals can be
used for power connections to an I/O Terminal Block with Box Terminals.
