BENTLY 106M1079-01監測器卡件,106M1079-01模塊
通信協處理器模塊（IC693CMM311）提供了高性能
所有Series 90-30模塊化CPU的協處理器（不能與嵌入式CPU一起使用-型號
311、313或323）。該模塊支持GE Fanuc CCM通信協議RTU
106M1079-01
（Modbus）從通信協議和SNP協議。該模塊有兩個串行端口。
端口1支持RS-232應用程序，端口2支持RS-232或RS-485應用程序。
可以使用配置軟件或默認設置配置模塊。
由于兩個串行端口都連接到模塊的單個連接器，因此需要使用IC693CBL305 Y形電纜
該模塊用于分離兩個端口，以便于接線。帶有331或BENTLY 106M1079-01
較高的CPU最多可以有四個CMM（僅在CPU基板中）。
The Communications Coprocessor Module (IC693CMM311) provides a high performance
coprocessor for all Series 90-30 modular CPUs (cannot be used with embedded CPUs - models
311, 313, or 323). This module supports the GE Fanuc CCM communications protocol, the RTU
(Modbus) slave communications protocol, and the SNP protocol. This module has two serial ports.
Port 1 supports RS-232 applications and Port 2 supports either RS-232 or RS-485 applications.
The module can be configured using the configuration software, or by using a default setup.
Since both serial ports are wired to the module’s single connector, an IC693CBL305 Wye cable is
supplied with this module to separate the two ports for ease of wiring. A system with a 331 or
higher CPU can have up to four CMMs (in the CPU baseplate only).
