VMIVME-4140燃機模塊,VMIVME-4140配置教程GE
輸入/輸出擴展總線
每個機箱的左上角有六個RS-485輸入/輸出擴展總線端口背板。
有兩套通道A、B和C的端口，提供兩個三重序列號
機箱之間的通信路徑。
每根電纜需要一套電纜
擴展機箱和RXM主機箱RXM模塊組。標準長度VMIVME-4140
電纜組（9000型）的長度為6英尺-如果需要，可以使用更長的電纜。
三重輸入/輸出總線傳輸數據
輸入/輸出模塊與主
每秒375千位的處理器。
VMIVME-4140燃機模塊
通信總線在
主處理器和通信模塊位于2兆位perKeyswitch，用于系統控制
主底盤有四個位置
控制所有
系統中的機箱。鑰匙開關
Tricon control lers、TriStation 1131軟件和
控制程序。開關設置為：
使用只讀功能運行正常操作。主處理器
I/O Expansion Bus
Each chassis has six RS-485 I/O expansion bus ports at the top left corner of
the backplane. There are two sets of
ports for channels A, B, and C,
providing for two triplicated serial
communications paths between chassis.
One set of cables is required for each
Expansion Chassis and for the RXM
Chassis which houses the primary
RXM Module set. The standard length
of a cable set (Model 9000) is 6 feet—
longer cables are available if needed.
The triplicated I/O bus transfers data
between the I/O modules and the Main
Processors at 375 kilobits per second.
The communication bus runs between
the Main Processors and the communication modules at 2 megabits perKeyswitch for System Control
The Main Chassis has a four-position
keyswitch which controls all the
chassis in the system. The keyswitch
setting is readable by Tricon controllers, TriStation 1131 software, and the
control programs. Switch settings are:
RUN—Normal operation with readonly capability. The Main Processors
