RELIANCE 57552-4驅動控制器模塊
1.產 品 資 料 介 紹：
中文資料：
RELIANCE 57552-4驅動控制器模塊是一款由Reliance Electric公司生產的產品，以下是對該模塊的詳細介紹：
基本信息
- 品牌：RELIANCE
- 型號：57552-4
- 系列：AutoMax PLC
- 零件號：57552-4
主要特點
- 通用性：57552-4是分布式電源系統通用驅動控制器模塊（UDC），最初是作為Reliance Electric AutoMax系統的一部分生產的。
- 可編程性：它是一種用戶可編程控制系統，使用微處理器實時控制交流和直流驅動器。
- 存儲能力：具有256 KB的非易失性讀/寫閃存、512 KB的易失性SRAM和4 KB的雙端口SRAM。
- 連接性：該模塊能夠使用光纖鏈路連接到兩個不同的PMI，并可以插入AutoMax卡架組件中，僅占用一個插槽。單個機架最多可插入10個UDC模塊，意味著單個機架能夠控制多達20個驅動器。
- 通信能力：它使用多總線與機架上的處理器模塊進行通信。
面板功能
- 面板上有一系列的六個LED指示燈，分別標記為Card OK、OS OK、COMM A OK、DRV A FLT、COM B OK和DRV B FLT。
- 有數字標記為1-3和NO的測試開關，以及數字標記為1-4和COM的儀表端口。
- 有兩組com端口，COMM A和COMM B，都標有XMT和RCV。
英文資料
RELIANCE 57552-4 driver controller module is a product produced by Reliance Electric. The following is a detailed introduction to this module:
Basic information
Brand: RELIANCE
Model: 57552-4
Series: AutoMax PLC
Part number: 57552-4
main features
Universality: 57552-4 is a Universal Driver Controller Module (UDC) for distributed power systems, originally produced as part of the Reliance Electric AutoMax system.
Programmability: It is a user programmable control system that uses microprocessors to control AC and DC drives in real-time.
Storage capacity: With 256 KB of non-volatile read/write flash memory, 512 KB of volatile SRAM, and 4 KB of dual port SRAM.
Connectivity: This module can be connected to two different PMIs using fiber optic links and can be inserted into AutoMax card rack components, occupying only one slot. A single rack can accommodate up to 10 UDC modules, which means a single rack can control up to 20 drives.
Communication capability: It uses multiple buses to communicate with processor modules on the rack.
Panel functions
There are a series of six LED indicator lights on the panel, labeled as Card OK, OS OK, COMM A OK, DRV A FLT, COM B OK, and DRV B FLT.
There are test switches labeled with numbers 1-3 and NO, as well as instrument ports labeled with numbers 1-4 and COM.
There are two sets of COM ports, COMM A and COMM B, both labeled with XMT and RCV.
2.產 品 展 示
3.產 品 展 示
