NI SCXI-1001機箱主機
1.產 品 資 料 介 紹：
中文資料：
NI SCXI-1001機箱主機是一款專為實驗室和工業環境中數據采集應用設計的機箱。以下是關于該機箱的詳細信息和特點：
- 產品概述：
- 品牌：National Instruments（NI）
- 型號：SCXI-1001
- 類型：低噪音、堅固耐用的機箱
- 設計特點：
- 緊湊性：機箱設計緊湊，適合各種環境中的數據采集需求。
- 堅固性：具有耐用的外殼，能夠保護內部電子設備免受環境條件的影響。
- 模塊容納能力：
- 機箱內部設計有12個插槽，可容納多達12個SCXI模塊，為用戶提供了高度的靈活性和可擴展性。
- 內部總線與定時電路：
- 機箱配備了3條內部模擬總線，用于模塊之間的通信和信號路由。
- 還包含用于高速多路復用的定時電路，確保數據采集的準確性和實時性。
- 信號調理與數據采集：
- 與SCXI模塊配合使用，用于信號調理和數據采集，可連接各種傳感器和信號源，進行放大、濾波和采集數據。
- 連接性：
- 機箱通常具有各種連接接口，包括電源接口、數據接口（如USB、Ethernet等）和時序觸發接口，以便與計算機和其他設備進行通信和協同工作。
- 軟件支持：
- NI通常提供了用于配置和控制SCXI模塊的軟件工具，這些工具可以幫助用戶設置和校準模塊，確保準確的數據采集。
- 應用領域：
- SCXI-1001機箱主機廣泛應用于實驗室研究、測試和測量應用中，包括物理學、工程學、生物醫學、自動化等領域。
- 可擴展性：
- 機箱設計具有一定的可擴展性，可以根據需要添加更多的插槽和模塊，以滿足不同應用的需求。
英文資料
The NI SCXI-1001 chassis host is a chassis designed specifically for data collection applications in laboratory and industrial environments. The following is detailed information and features about the chassis:
Product Overview:
Brand: National Instruments (NI)
Model: SCXI-1001
Type: Low noise, sturdy and durable chassis
Design features:
Compact: The chassis design is compact and suitable for data collection needs in various environments.
Durability: With a durable casing, it can protect internal electronic devices from environmental conditions.
Module capacity:
The internal design of the chassis has 12 slots, which can accommodate up to 12 SCXI modules, providing users with high flexibility and scalability.
Internal bus and timing circuit:
The chassis is equipped with three internal analog buses for communication and signal routing between modules.
It also includes a timing circuit for high-speed multiplexing to ensure the accuracy and real-time performance of data acquisition.
Signal conditioning and data acquisition:
Used in conjunction with the SCXI module for signal conditioning and data acquisition, it can connect various sensors and signal sources for amplification, filtering, and data acquisition.
Connectivity:
The chassis usually has various connection interfaces, including power interface, data interface (such as USB, Ethernet, etc.), and timing trigger interface, for communication and collaborative work with computers and other devices.
Software support:
NI typically provides software tools for configuring and controlling SCXI modules, which can help users set up and calibrate modules to ensure accurate data collection.
Application field:
The SCXI-1001 chassis host is widely used in laboratory research, testing, and measurement applications, including physics, engineering, biomedical, automation, and other fields.
Scalability:
The chassis design has a certain degree of scalability, and more slots and modules can be added as needed to meet the needs of different applications.
2.產 品 展 示
3.產 品 展 示
