TRICONEX DI3301冗余模塊,DI3301卡件
64點數字輸入
模塊
每個64點數字輸入（DI）
模塊有三個隔離通道
獨立處理所有數據TRICONEX DI3301
輸入到模塊。微處理器
在每個通道上掃描每個輸入點，
編譯數據并將其傳輸?shù)?/p>
按需提供主處理器。然后
輸入數據在處理之前在主進程或SOR上進行表決，以確保
最高誠信。
所有數字輸入模塊支持
為每個
頻道任何通道上的故障都會激活故障指示燈，從而
激活底盤警報。TMR
模塊保證在出現單一故障時正常運行，并且
可與某些類型的TRICONEX DI3301
多個故障。
所有數字輸入模塊都支持熱備用模塊，并且需要單獨的
外部終端面板（ETP），帶有
Tricon背板的電纜接口。
每個模塊通過機械鍵連接到
防止在
底盤。
64-Point Digital Input
Modules
Each 64-point Digital Input (DI)
module has three isolated channels
which independently process all data
input to the module. A microprocessor
on each channel scans each input point,
compiles data and transmits it to the
Main Processors on demand. Then
input data is voted at the Main Proces
sors just prior to processing to ensure
the highest integrity.
All Digital Input Modules sustain
complete, ongoing diagnostics for each
channel. A failure on any channel acti
vates the Fault indicator which in turn
activates the chassis alarm. A TMR
module is guaranteed to operate prop
erly in the presence of a single fault and
may operate properly with certain kinds
of multiple faults.
All Digital Input Modules support hot
spare modules and require a separate
external termination panel (ETP) with a
cable interface to the Tricon backplane.
Each module is mechanically keyed to
prevent improper installation in a
chassis.
