MOOG D138-002-002加密狗,使用教程D138-002-002
終端組件和電纜
現場輸入信號通過以下方式連接到FBM子系統DIN導軌安裝終端組件電無源（見圖1）。助教FBM201/b/c/d模塊有以下幾種
形式：
使用聚酰胺（PA）的壓縮螺釘型
使用聚氯乙烯的壓縮螺釘型（PVC）材料
使用聚酰胺（PA）材料的環耳型
使用聚氯乙烯（PVC）的環耳型
MOOG D138-002-002加密狗第8頁的“終端組件”，以獲取與FBM201/b/c/d模塊一起使用的TA。
可拆卸終端電纜連接DIN導軌通過上的現場連接器將TA安裝到FBM安裝FBM的底板。結束
電纜有以下幾種材料：
聚氨酯
Hypalon XLP。終端電纜有多種類型長度可達30米（98英尺），允許
終端組件安裝在外殼或相鄰外殼中。見表2用于TAs的終端電纜列表
FBM201/b/c/d模塊。
TERMINATION ASSEMBLIES AND CABLES
Field input signals connect to the FBM subsystem via
DIN rail mounted Termination Assemblies, which are
electrically passive (see Figure 1). TAs for the
FBM201/b/c/d modules are available in the following
forms:
Compression screw type using Polyamide (PA)
material
Compression screw type using Polyvinyl Chloride
(PVC) material
Ring lug type using Polyamide (PA) material
Ring lug type using Polyvinyl Chloride (PVC)
material
See “FUNCTIONAL SPECIFICATIONS –
TERMINATION ASSEMBLIES” on page 8 for a list of
TAs used with the FBM201/b/c/d modules.
A removable termination cable connects the DIN rail
mounted TA to the FBM via a field connector on the
baseplate in which the FBM is installed. Termination
cables are available in the following materials:
Polyurethane
Hypalon XLP.
Termination cables are available in a variety of
lengths, up to 30 meters (98 feet), allowing the
Termination Assembly to be mounted in either the
enclosure or in an adjacent enclosure. See Table 2
for a list of termination cables used with the TAs for
the FBM201/b/c/d modules.
