There are two ways of configuring the SST-PB3-CLX-RLL in RSLogix 5000; Generic 1756
Module type and AOP (Add-on-Profile). Generic 1756 Module is supported in all versions of
RSLogix 5000. AOP is supported in RSLogix 5000 versions 15 and higher. AOP is the
recommended method since it allows you to configure all options on the SST-PB3-CLX-RLL via
a GUI. AOP generates data tags that are more specific to the module. Diagnostic tags are easier
to identify and the I/O tags are separated from the command control registers. You no longer
have to edit values in the module’s configuration array to configure the module as a DP Slave or
DP Master and Slave. The configuration file is automatically updated when you select options in
the AOP interface. For customers with existing applications, the project can be upgraded to use
the AOP profile but it will be necessary to delete the Generic profile prior to using AOP profile.
This includes updating ladder logic to use AOP tags instead of generic tags and then deleting the
generic tags. AOP and generic sample ladder code is available.
If you need to reduce the size of the I/O tables you must use 1756-Generic profile. I/O sizes are
fixed at their maximum sizes in AOP. To configure through RSLogix 5000 using 1756-Generic
profile, see section on Generic 1756 Module.
5.1.2 AOP Requirements
? Rockwell RSLogix 5000 Version 15 or later.
The following are available on the SST Backplane Communication Module Products CD
v1.7.0.0 and on our webs site www.wooodhead.com.
?
Backplane firmware module Pbfclx.ss4 version 8.6
?
Profibus firmware module Pfbclx.ss3 7.26
?
Rockwell’s RSLogix 5000 AOP installation 1.21.1.0
?
SST Profibus Configuration Tool v 3.13.13.0
?
RSLogix 5000 Ladder sample code using AOP (Created in RSLogix 5000 Version 15)
o
sstpb3clx_main_AOP_example.ACD
o
DPV1_ReadClass1_AOP.ACD
o
DPV1_ReadClass2_AOP.ACD
o
sstpfbclx_IO_Expansion_AOP.ACD
