IC698CHS009框架,GE使用尺寸IC698CHS009
從機配置和編程
如果要在中為CLX從屬數據定義自己的偏移量ControlLogix配置文件，它們必須大于主配置中從機的數據偏移量。例如，如果CLX主設備用于從設備的最大輸入偏移量為201字輸入，則從機RX偏移可設置為21或更大。CLX從屬數據可以映射到0以外的頁面。這個配置工具將不知道映射從屬的偏移量數據到，因此如果要將主數據映射到同一頁，請不要重疊工具指定的地址。
CLX從機在通電后僅接受一次ControlLogix配置。這意味著如果通電后更改ControlLogix配置文件設置（站號，波特率等），并將其下載到ControlLogix PLC，新設置將不會生效。
IC698CHS009框架有三種方法可以接受新的配置設置：
1、在接受新的配置設置之前，先接通模塊電源。
2、遵循以下步驟：
a、 將PLC置于PROG模式
b、 通過配置工具串行連接到模塊
c、 發出脫機命令
d、 編輯ControlLogix文件
e、 下載PLC程序
f、 將PLC置于運行模式
3、遵循以下步驟：
a、 將PLC置于PROG模式
b、 通過配置工具串行連接到模塊
c、 發出脫機命令
d、 通過RSLogix與PLC聯機時編輯ControlLogix文件
e、 使用RSLogix 5000中的禁止功能禁用和啟用連接
在“輸入/輸出配置”>“模塊屬性”>“連接”選項卡下
Slave Configuration and Programming
Note
If you’re defining your own offsets for CLX slave data in the
ControlLogix configuration file, they must be greater than the highest
data offset of the slave in the master configuration. So, for example,
if the highest input offset the CLX master uses for a slave is 20 with
1 word input, then the slave RX offset could be set to 21 or greater.
CLX slave data can be mapped to a page other than 0. The
Configuration Tool will not know which offsets you mapped your slave
data to, so if you are mapping Master data to the same page, do not
overlap the addresses assigned by the Tool.
The CLX slave accepts the ControlLogix configuration only once after power-up. This means
that if after power-up you change the ControlLogix configuration file settings (Station number,
baud rate and so on) in your RSLogix 5000 Program and download it to the ControlLogix PLC,
the new setting will not take effect.
There are three ways to have the new configuration settings accepted:
1.
Cycle power on the module before new configuration settings are accepted.
2.
Follow these steps:
a.
Put the PLC into PROG mode
b.
Connect serially to the module via the Configuration Tool
c.
Issue the Offline command
d.
Edit the ControlLogix file
e.
Download the PLC program
f.
Put the PLC into RUN mode
3.
Follow these steps:
a. Put the PLC into PROG mode
b. Connect serially to the module via the Configuration Tool
c. Issue the Offline command
d. Edit the ControlLogix file while Online with PLC via RSLogix
e. Disable and enable connection by using the inhibit function in RSLogix 5000
under I/O configuration > Module Properties > Connection tab
