NI SCXI-1326電壓模塊,SCXI-1326使用尺寸
快速設置指導您完成設置張力電子設備的最少步驟。
要求您回答一些問題并輸入所需的值。這些選擇和必須進行參數設置，以使張力電子設備做好測量準備。
在快速設置中僅設置有限數量的選擇和參數設置。所有其他參數設置為出廠默認值。見附錄A.4出廠默認設置。
根據包裹增益的設置方式，可以通過兩種方式進行快速設置。
可通過選擇“懸掛重量”或“輸入包裹增益”來設置包裹增益。
NI SCXI-1326電壓模塊?使用吊重?使用包裹增益
懸掛重量和包裹增益在第3.12.5節中解釋。檢查稱重傳感器信號極性這是一種檢查稱重傳感器是否連接以提供正輸出的簡單方法張力電子設備的信號變化，導致卷筒紙張力增加。
1、用手推動，在一個負載上施加與增加的腹板張力相對應的力一次測量一個傳感器（盡可能靠近稱重傳感器），并檢查顯示讀數是否為積極樂觀的如果顯示讀數為負值，則將稱重傳感器信號連接反向至張力電子設備。
如果你不知道力的作用方向，以相同的力方向連接稱重傳感器A和B。
要改變稱重傳感器A的極性，請反轉X1:5和6（在A+和A-）。要更改稱重傳感器B的極性，請反轉X1:9和10（在B+和B-）。
2、改變稱重傳感器極性后，檢查顯示屏讀數是否為正值腹板張力。
3.10檢查稱重傳感器功能“懸掛重量”程序也可用作稱重傳感器的功能測試，稱重傳感器。應注意輸出信號，繩索應靠近另一根繩索移動
稱重傳感器。檢查輸出信號的差異是否很小。
Checking Load Cell Signal Polarity
This is a simple method to check that the load cells are connected to give a positive output
signal change from the tension electronics for increased web tension.
1. Push with your hand to apply a force corresponding to increased web tension on one load
cell at a time (as close to the load cell as possible) and check if the display reading is
positive. If the display reading is negative, invert the load cell signal connection to the
tension electronics.
NOTE
If you don’t know in which direction the force is acting,
connect load cell A and B with the same force direction.
To change the polarity of load cell A, invert X1:5 and 6 (In A+ and In A-).
To change the polarity of load cell B, invert X1:9 and 10 (In B+ and In B-).
2. After changing load cell polarity, check that the display reading is positive for increased
web tension.
3.10 Checking Load Cell Function
The “Hanging Weight” procedure can also be used as a function test on load cells,
see Section 3.8.1.
The rope should then be placed in the web path but as close as possible to one of the
load cells. The output signal should be noted, and the rope moved close to the other
load cell. Check that the difference in output signal is small.
