FSC CC12403系統卡件,CC12403使用指導
在正常操作條件下，您的系統不需要任何維護。然而我們建議您進行定期檢查。可采取以下預防措施取決于系統運行的環境類型。
5.2預防性維護單位測量值稱重傳感器可防止稱重傳感器長時間接觸腐蝕性元素。
檢查固定螺釘，必要時重新擰緊。
檢查稱重傳感器和轉接板之間的間隙確保它們不會被污垢堵塞可能導致分路力進入稱重傳感器。
如有必要，用壓縮空氣清潔間隙。
FSC CC12403系統卡件張力電子設備檢查電路板是否正確固定電纜或電線沒有損壞。
檢查所有端子螺釘和電纜密封套正確擰緊。
連接電纜檢查稱重傳感器和張力電子裝置
損壞在測量系統的工作壽命期間，可能會發生干擾其和過程這些干擾可能以多種不同的方式出現，故障原因可能很難找到。然而，性質相似的擾動可以組合在一起通常它們有相同或相似的錯誤來源。
本章中的故障跟蹤說明將幫助您快速找到并糾正常見故障。
6.2安全說明
追蹤故障時，請閱讀并遵循第1章引言中給出的安全說明。
但是，如果更嚴格，應以當?shù)胤ㄒ?guī)為準。
Under normal operating conditions, your system does not require any maintenance. However,
we recommend you to perform regular checks. The following preventive measures may be
taken depending on the type of environment in which your system operates.
5.2 Preventive Maintenance
Unit Measures
Load cells Protect the load cells from prolonged contact with
corrosive elements.
Check the fixing screws and re-tighten if necessary.
Check the gaps between load cell and adapter plates
to ensure that they are not clogged with dirt, which
can cause a shunt force into the load cell.
Clean the gaps with compressed air if necessary.
Tension Electronics Check that the circuit boards are properly secured
and that cables or wires are not damaged.
Check that all terminal screws and cable glands
are properly tightened.
Connection cables Check that the connection cables between the
load cells and the tension electronics are not
damaged.During the working life of your measurement system, events may occur that disturb it and your
process. These disturbances may appear in many different ways and the reason for the fault can
be difficult to find. However, disturbances similar in character can be grouped together and
usually they have the same or similar sources of error.
The fault-tracing instructions in this chapter will help you to quickly find and correct the most
common faults.
6.2 Safety Instructions
