Multilin C30J03HCF6HH6H控制器
1.產 品 資 料 介 紹：
中文資料：
GE Multilin C30J03HCF6HH6H 是一款多功能控制器，專用于電力系統的保護、控制和監測。它集成了多種功能，提供高級的保護和控制能力，適合各種電力應用。以下是該控制器的詳細信息：
產品概述
- 型號：C30J03HCF6HH6H
- 產品類型：控制器
主要特點
- 多功能保護：支持多種保護功能，包括過電流、欠壓、過壓、接地故障等，適用于復雜的電力系統需求。
- 高級控制功能：具備先進的控制功能，如自動重啟、邏輯控制、延時操作等。
- 實時監控：提供實時的數據監測和系統狀態反饋，包括電流、電壓、功率等參數。
- 用戶界面：配備易于使用的圖形用戶界面（GUI），便于配置和操作。
- 通信能力：支持多種通信協議（如Modbus、DNP3、IEC 61850），便于與其他系統和設備集成。
技術規格
- 型號：C30J03HCF6HH6H
- 保護功能：
- 過電流保護：監測電流超過預設值的情況，并采取保護措施。
- 欠壓/過壓保護：檢測電壓異常，防止設備損壞。
- 接地故障保護：監測接地故障，并提供相關保護。
- 熱保護：防止設備因過熱而損壞。
- 控制功能：包括自動重啟、延時操作、邏輯控制等高級功能。
- 數據采集：實時采集和分析電流、電壓、功率因數等數據。
- 顯示與界面：高分辨率顯示屏和用戶友好的操作界面。
- 通訊接口：支持多種通信協議，如Modbus、DNP3、IEC 61850。
- 環境溫度：通常適應0°C到50°C的工作溫度范圍。
- 安裝方式：支持面板安裝或DIN導軌安裝。
應用領域
- 電力系統控制：用于電力系統中的控制和保護，確保系統的安全和穩定。
- 工業自動化：在工業自動化系統中提供高級控制和保護功能。
- 建筑電力管理：適用于建筑物內的電力系統管理和保護。
- 能源管理：幫助優化能源使用，提供詳細的監測和控制功能。
安裝與維護
- 安裝：設備通常通過面板或DIN導軌安裝，具體安裝方式請參考產品手冊。
- 維護：設計簡潔，易于日常維護和檢查。建議定期檢查設備狀態和連接線，以確保正常運行。
優勢
- 全面保護：集成多種保護功能，確保系統的安全運行。
- 先進控制：提供靈活的控制功能，適應不同的應用需求。
- 強大通信能力：支持多種通信協議，便于系統集成。
- 用戶友好：直觀的用戶界面和操作功能，簡化配置和監控過程。
總結
GE Multilin C30J03HCF6HH6H 控制器是一款功能全面的設備，專為電力系統中的保護、控制和監測需求設計。其多功能保護、高級控制能力和強大的通信能力使其成為各種電力應用中的理想選擇。
英文資料：
GE Multilin C30J03HCF6HH6H is a multifunctional controller designed for the protection, control, and monitoring of power systems. It integrates multiple functions, provides advanced protection and control capabilities, and is suitable for various power applications. The following is the detailed information of the controller:
Product Overview
Model: C30J03HCF6HH6H
Product type: Controller
main features
Multi functional protection: supports multiple protection functions, including overcurrent, undervoltage, overvoltage, ground fault, etc., suitable for complex power system requirements.
Advanced control functions: equipped with advanced control functions such as automatic restart, logic control, delayed operation, etc.
Real time monitoring: Provides real-time data monitoring and system status feedback, including parameters such as current, voltage, and power.
User Interface: Equipped with an easy-to-use graphical user interface (GUI) for easy configuration and operation.
Communication capability: Supports multiple communication protocols (such as Modbus DNP3、IEC 61850）， Easy to integrate with other systems and devices.
technical specifications
Model: C30J03HCF6HH6H
Protection function:
Overcurrent protection: Monitor the situation where the current exceeds the preset value and take protective measures.
Undervoltage/Overvoltage Protection: Detect abnormal voltage to prevent equipment damage.
Ground fault protection: Monitor ground faults and provide relevant protection.
Thermal protection: prevents equipment from being damaged due to overheating.
Control functions: including advanced features such as automatic restart, delayed operation, and logic control.
Data collection: Real time collection and analysis of current, voltage, power factor, and other data.
Display and Interface: High resolution display screen and user-friendly interface.
Communication interface: Supports multiple communication protocols, such as Modbus, DNP3, IEC 61850.
Environmental temperature: typically suitable for a working temperature range of 0 ° C to 50 ° C.
Installation method: Supports panel installation or DIN rail installation.
application area
Power system control: used for control and protection in the power system, ensuring the safety and stability of the system.
Industrial automation: providing advanced control and protection functions in industrial automation systems.
Building power management: applicable to the management and protection of power systems within buildings.
Energy management: Help optimize energy use, provide detailed monitoring and control functions.
Installation and maintenance
Installation: The equipment is usually installed through a panel or DIN rail. Please refer to the product manual for specific installation methods.
Maintenance: The design is simple and easy to maintain and inspect on a daily basis. It is recommended to regularly check the equipment status and connection wires to ensure normal operation.
advantage
Comprehensive protection: integrates multiple protection functions to ensure the safe operation of the system.
Advanced Control: Provides flexible control functions to adapt to different application requirements.
Powerful communication capability: Supports multiple communication protocols for easy system integration.
User friendly: intuitive user interface and operational functions, simplifying the configuration and monitoring process.
summary
The GE Multilin C30J03HCF6HH6H controller is a comprehensive device designed specifically for protection, control, and monitoring needs in power systems. Its multifunctional protection, advanced control capabilities, and powerful communication capabilities make it an ideal choice for various power applications.
2.產 品 展 示
