MULTILIN 369-HI-0-M-0-E電機管理繼電器
1.產 品 資 料 介 紹：
中文資料：
GE Multilin 369-HI-0-M-0-E 是一款高性能的電機管理繼電器，設計用于提供電機保護、監控和控制。它集成了多種保護功能，適用于各種電力系統和工業應用。以下是該繼電器的詳細信息：
產品概述
- 型號：369-HI-0-M-0-E
- 產品類型：電機管理繼電器
主要特點
- 多功能保護：集成了多種電機保護功能，如過載保護、堵轉保護、熱保護、欠壓保護、過壓保護等。
- 高級控制功能：支持自動重啟、邏輯控制、延時操作等功能，提供靈活的電機控制方案。
- 實時監控：能夠實時監控電機的運行狀態和性能，包括電流、電壓、功率等參數。
- 用戶界面：配備直觀的圖形用戶界面（GUI），便于配置、操作和監控。
- 通信能力：支持多種通信協議（如Modbus、DNP3、IEC 61850），方便與其他設備和系統集成。
技術規格
- 型號：369-HI-0-M-0-E
- 保護功能：
- 過載保護：檢測電機負載超出預設值的情況，并觸發保護措施。
- 堵轉保護：防止電機在堵轉狀態下運行，減少設備損壞風險。
- 熱保護：監測電機溫度，防止過熱。
- 欠壓保護：防止電機在欠壓條件下運行，確保設備安全。
- 過壓保護：防止電機在過壓條件下運行，保證系統穩定。
- 控制功能：包括自動重啟、延時操作、邏輯控制等，適應多種控制需求。
- 數據采集：支持電流、電壓、功率因數等參數的實時采集和分析。
- 顯示與界面：高分辨率顯示屏和用戶友好的操作界面。
- 通訊接口：支持多種通信協議，如Modbus、DNP3、IEC 61850。
- 環境溫度：通常適應0°C到50°C的工作溫度范圍。
- 安裝方式：支持面板安裝或DIN導軌安裝。
應用領域
- 電機保護：用于電力系統中的電機保護，確保其安全穩定運行。
- 工業自動化：提供電機保護和控制功能，適用于工業自動化系統。
- 建筑電力管理：適用于建筑物內的電機保護和管理，防止設備損壞。
- 能源管理：提供詳細的電機運行數據和保護功能，幫助優化能源使用。
安裝與維護
- 安裝：設備通常通過面板或DIN導軌安裝，具體方式請參考產品手冊。
- 維護：設計簡潔，便于日常維護和檢查。建議定期檢查設備狀態和連接線，以確保正常運行。
優勢
- 全面保護：集成多種保護功能，確保電機的安全運行。
- 靈活控制：提供多種控制選項，適應不同的應用需求。
- 強大通信能力：支持多種通信協議，便于與其他設備和系統集成。
- 用戶友好：直觀的用戶界面和功能，簡化操作和配置過程。
總結
GE Multilin 369-HI-0-M-0-E 電機管理繼電器是一款高性能的保護和控制設備，專為電機管理設計。其綜合的保護功能、高級控制能力和強大的通信能力使其成為各種電力和工業應用中的理想選擇。
英文資料：
GE Multilin 369-HI-0-M-0-E is a high-performance motor management relay designed to provide motor protection, monitoring, and control. It integrates multiple protection functions and is suitable for various power systems and industrial applications. The following is the detailed information of the relay:
Product Overview
Model: 369-HI-0-M-0-E
Product Type: Motor Management Relay
main features
Multi functional protection: It integrates multiple motor protection functions, such as overload protection, locked rotor protection, thermal protection, undervoltage protection, overvoltage protection, etc.
Advanced control function: supports automatic restart, logic control, delayed operation and other functions, providing flexible motor control solutions.
Real time monitoring: It can monitor the operating status and performance of the motor in real time, including parameters such as current, voltage, and power.
User Interface: Equipped with an intuitive graphical user interface (GUI) for easy configuration, operation, and monitoring.
Communication capability: Supports multiple communication protocols (such as Modbus DNP3、IEC 61850）， Facilitate integration with other devices and systems.
technical specifications
Model: 369-HI-0-M-0-E
Protection function:
Overload protection: detects the situation where the motor load exceeds the preset value and triggers protective measures.
Locking protection: prevents the motor from running in a locked state, reducing the risk of equipment damage.
Thermal protection: Monitor motor temperature to prevent overheating.
Undervoltage protection: prevents the motor from operating under undervoltage conditions, ensuring equipment safety.
Overvoltage protection: prevents the motor from operating under overvoltage conditions, ensuring system stability.
Control functions: including automatic restart, delayed operation, logic control, etc., suitable for various control needs.
Data collection: supports real-time collection and analysis of parameters such as current, voltage, and power factor.
Display and Interface: High resolution display screen and user-friendly interface.
Communication interface: Supports multiple communication protocols, such as Modbus, DNP3, IEC 61850.
Environmental temperature: typically suitable for a working temperature range of 0 ° C to 50 ° C.
Installation method: Supports panel installation or DIN rail installation.
application area
Motor protection: used for motor protection in power systems to ensure their safe and stable operation.
Industrial Automation: Provides motor protection and control functions, suitable for industrial automation systems.
Building power management: applicable to the protection and management of motors inside buildings to prevent equipment damage.
Energy management: Provide detailed motor operation data and protection functions to help optimize energy use.
Installation and maintenance
Installation: The device is usually installed through a panel or DIN rail. Please refer to the product manual for specific instructions.
Maintenance: The design is simple and easy to maintain and inspect on a daily basis. It is recommended to regularly check the equipment status and connection wires to ensure normal operation.
advantage
Comprehensive protection: integrates multiple protection functions to ensure the safe operation of the motor.
Flexible control: Provides multiple control options to adapt to different application needs.
Powerful communication capability: Supports multiple communication protocols, making it easy to integrate with other devices and systems.
User friendly: intuitive user interface and functionality, simplifying the operation and configuration process.
summary
The GE Multilin 369-HI-0-M-0-E motor management relay is a high-performance protection and control device designed specifically for motor management. Its comprehensive protection functions, advanced control capabilities, and powerful communication capabilities make it an ideal choice for various power and industrial applications.
2.產 品 展 示
