Multilin MS2000PDU電機保護系統
1.產 品 資 料 介 紹：
中文資料：
Multilin MS2000PDU 是 GE 提供的一款電機保護和控制系統，專門設計用于電動機保護、監控和管理。該系統提供了一整套全面的保護、控制和診斷功能，適用于各種工業和商業應用中的電動機系統。
主要功能和特點
全面的電機保護
- 過載保護：防止電動機在長期過載條件下運行，避免設備損壞。
- 短路保護：檢測電動機上的短路故障，并提供快速的斷電保護。
- 接地故障保護：監測接地故障，避免因接地問題導致的設備損壞。
- 過電壓/欠電壓保護：保護電動機免受電壓異常（過高或過低）的影響。
- 失步保護：防止電動機因失步或其他異常運行狀況而受損。
監測和診斷
- 實時監測：監測電動機的運行參數，如電流、電壓、功率因數和頻率等。
- 故障診斷：提供詳細的故障記錄和診斷信息，幫助快速定位和解決問題。
- 數據記錄：記錄電動機的運行數據，包括歷史事件和操作記錄，用于分析和優化。
控制功能
- 自動控制：可以根據設定的條件自動啟動或停止電動機，簡化操作。
- 遠程控制：支持通過通信接口進行遠程控制和管理，提高操作便利性。
通信和集成
- 多種通信協議：支持常見的通信協議（如Modbus、DNP3、IEC 61850等），便于與SCADA系統和其他控制系統集成。
- 數據傳輸：實現實時數據傳輸和遠程監控，支持系統集成和優化管理。
用戶界面
- 圖形化顯示：提供直觀的顯示界面，簡化操作和配置過程。
- 靈活配置：允許用戶根據具體需求配置保護參數和控制功能。
高可靠性
- 隔離保護：具有電氣隔離功能，防止干擾和故障傳播。
- 抗干擾能力：設計上考慮了工業環境的要求，具備較強的耐用性和抗干擾能力。
應用領域
工業自動化
- 電動機保護：在工業生產線中保護電動機，防止因過載、短路等故障導致的設備損壞。
- 過程控制：用于自動化系統中的電動機控制，提高生產過程的效率和穩定性。
發電廠
- 發電機保護：保護發電機免受各種故障影響，確保發電機的可靠運行。
- 系統監測：提供對發電廠內電動機系統的全面監測和控制，優化設備運行和維護。
配電系統
- 配電設備保護：保護配電網絡中的電動機設備，防止故障對系統造成的影響。
- 控制和監測：實現對配電系統的控制和監測，提高系統的安全性和可靠性。
變電站
- 變壓器風機保護：保護變電站中的變壓器風機和其他電動機設備，確保變電站的正常運行。
- 設備管理：監控和管理變電站內的電動機設備，提高設備的運行效率和維護支持。
Multilin MS2000PDU 電機保護系統憑借其先進的保護、監控和控制功能，幫助用戶提升電動機系統的安全性、可靠性和管理效率，是電力系統和工業自動化中重要的保護工具。
英文資料：
Multilin MS2000PDU is a motor protection and control system provided by GE, specifically designed for motor protection, monitoring, and management. This system provides a comprehensive set of protection, control, and diagnostic functions, suitable for motor systems in various industrial and commercial applications.
Main functions and features
Comprehensive motor protection
Overload protection: prevents the motor from operating under long-term overload conditions and avoids equipment damage.
Short circuit protection: detect short circuit faults on the motor and provide quick power-off protection.
Ground fault protection: Monitor ground faults to avoid equipment damage caused by grounding issues.
Overvoltage/undervoltage protection: protects the motor from the effects of abnormal voltage (too high or too low).
Out of step protection: prevents the motor from being damaged due to out of step or other abnormal operating conditions.
Monitoring and Diagnosis
Real time monitoring: Monitor the operating parameters of the motor, such as current, voltage, power factor, and frequency.
Fault diagnosis: Provide detailed fault records and diagnostic information to help quickly locate and solve problems.
Data recording: Record the operating data of the motor, including historical events and operation records, for analysis and optimization.
control function
Automatic control: It can automatically start or stop the motor according to the set conditions, simplifying the operation.
Remote control: Supports remote control and management through communication interfaces, improving operational convenience.
Communication and integration
Multiple communication protocols: Supports common communication protocols such as Modbus, DNP3, IEC 61850, etc., making it easy to integrate with SCADA systems and other control systems.
Data transmission: Achieve real-time data transmission and remote monitoring, support system integration and optimized management.
user interface
Graphic display: Provides an intuitive display interface, simplifying the operation and configuration process.
Flexible configuration: allows users to configure protection parameters and control functions according to specific needs.
high reliability
Isolation protection: It has electrical isolation function to prevent interference and fault propagation.
Anti interference capability: The design takes into account the requirements of industrial environments and has strong durability and anti-interference ability.
application area
industrial automation
Motor protection: Protecting motors in industrial production lines to prevent equipment damage caused by overload, short circuit, and other faults.
Process control: used for motor control in automation systems to improve the efficiency and stability of the production process.
power plant
Generator protection: Protect the generator from various faults and ensure its reliable operation.
System monitoring: Provide comprehensive monitoring and control of the electric motor system within the power plant, optimize equipment operation and maintenance.
Distribution system
Power distribution equipment protection: Protect the motor equipment in the power distribution network to prevent the impact of faults on the system.
Control and Monitoring: Implement control and monitoring of the power distribution system to improve its safety and reliability.
transformer substation
Transformer fan protection: protects transformer fans and other motor equipment in the substation to ensure the normal operation of the substation.
Equipment management: Monitor and manage the electric motor equipment in the substation to improve the operational efficiency and maintenance support of the equipment.
The Multilin MS2000PDU motor protection system, with its advanced protection, monitoring, and control functions, helps users improve the safety, reliability, and management efficiency of motor systems. It is an important protection tool in power systems and industrial automation.
2.產 品 展 示
