Multilin F650BABF2G1HI6海灣保護系統
1.產 品 資 料 介 紹：
中文資料：
Multilin F650BABF2G1HI6 是 GE Multilin 系列中的數字保護控制器，主要用于電力系統中的保護、控制和監測。它設計用于保護輸配電系統中的變電站、開關設備和其他關鍵基礎設施，確保系統的安全和穩定。
主要功能和特點
綜合保護功能
- 過流保護：提供快速和精確的過流保護，防止線路和設備因過電流損壞。
- 接地保護：監測接地故障并提供保護，確保系統的安全性。
- 過壓和欠壓保護：檢測電壓異常情況，并采取相應措施，防止設備損壞。
控制功能
- 斷路器控制：支持?jǐn)嗦菲鞯倪h(yuǎn)程和本地控制，提供自動重合閘功能，確保電力系統的連續運行。
- 電容器控制：管理電容器組的運行，提高電力系統的功率因數和穩定性。
監測和數據記錄
- 實時監測：提供實時監測功能，跟蹤系統的運行狀態和關鍵參數。
- 故障記錄：記錄故障事件和運行數據，幫助用戶進行故障分析和診斷。
通信和接口
- 多種通信協議：支持Modbus、DNP3、IEC 61850等多種通信協議，確保與其他系統的兼容性。
- 網絡接口：配備以太網接口，支持遠程監控和控制。
- 串行接口：提供RS-232、RS-485等串行通信接口，便于與其他設備的連接。
用戶界面和配置
- LCD顯示屏：集成LCD顯示屏，提供直觀的用戶界面，方便用戶查看和設置參數。
- 配置軟件：通過配置軟件進行參數設置和管理，簡化系統的配置和維護。
模塊化設計
- 靈活配置：采用模塊化設計，用戶可以根據具體需求選擇不同的功能模塊，靈活配置系統。
- 易于維護：模塊化結構便于系統的維護和升級，降低了維護成本。
高可靠性
- 冗余設計：具有電源和通信的冗余設計，確保系統的高可靠性和可用性。
- 環境適應性：能夠在嚴苛的環境條件下穩定運行，適應不同的應用場景。
應用領域
變電站保護
- 主變保護：為變電站中的主變壓器提供全面的保護和控制功能，確保變壓器的安全運行。
- 母線保護：監測和保護變電站中的母線，防止故障擴大，保障電力系統的穩定。
輸配電系統
- 線路保護：為輸電線路提供高效的保護，防止故障引發大范圍停電。
- 分段保護：對配電系統中的各個分段進行保護和控制，提高配電網絡的可靠性。
工業電力系統
- 電機保護：保護工業電力系統中的大型電機和關鍵設備，防止因故障導致的生產中斷。
- 發電機保護：為工業發電設備提供全面的保護和監控，確保發電系統的安全運行。
可再生能源
- 風電場保護：為風電場中的變電站和輸電線路提供保護，保障風電系統的穩定性。
- 光伏電站保護：監測和保護光伏電站中的關鍵設備，防止故障影響電力輸出。
總結
Multilin F650BABF2G1HI6 數字保護控制器為電力系統提供了可靠的保護、控制和監測解決方案，廣泛應用于變電站、輸配電系統、工業電力系統和可再生能源等領域，確保電力系統的安全性和穩定性。
英文資料：
The Multilin F650BABF2G1HI6 is a digital protection controller in the GE Multilin series, mainly used for protection, control, and monitoring in power systems. It is designed to protect substations, switchgear, and other critical infrastructure in power transmission and distribution systems, ensuring the safety and stability of the system.
Main functions and features
Comprehensive protection function
Overcurrent protection: Provides fast and accurate overcurrent protection to prevent damage to circuits and equipment due to overcurrent.
Grounding protection: Monitor grounding faults and provide protection to ensure the safety of the system.
Overvoltage and undervoltage protection: detect abnormal voltage conditions and take corresponding measures to prevent equipment damage.
control function
Circuit breaker control: supports remote and local control of circuit breakers, provides automatic reclosing function, and ensures the continuous operation of the power system.
Capacitor control: Manage the operation of capacitor banks to improve the power factor and stability of the power system.
Monitoring and data recording
Real time monitoring: Provides real-time monitoring function to track the operating status and key parameters of the system.
Fault record: Record fault events and operational data to assist users in fault analysis and diagnosis.
Communication and Interface
Multiple communication protocols: Supports Modbus, DNP3, IEC 61850 and other communication protocols to ensure compatibility with other systems.
Network interface: equipped with Ethernet interface, supporting remote monitoring and control.
Serial interface: Provides serial communication interfaces such as RS-232 and RS-485 for easy connection with other devices.
User interface and configuration
LCD display screen: Integrated LCD display screen, providing an intuitive user interface, convenient for users to view and set parameters.
Configuration software: Simplify system configuration and maintenance by setting and managing parameters through configuration software.
Modular design
Flexible configuration: Adopting modular design, users can choose different functional modules according to specific needs and flexibly configure the system.
Easy to maintain: The modular structure facilitates system maintenance and upgrades, reducing maintenance costs.
high reliability
Redundancy design: A redundant design with power and communication to ensure high reliability and availability of the system.
Environmental adaptability: able to operate stably under harsh environmental conditions and adapt to different application scenarios.
application area
Substation protection
Main transformer protection: provides comprehensive protection and control functions for the main transformers in the substation, ensuring the safe operation of the transformers.
Busbar protection: Monitor and protect the busbars in substations to prevent the expansion of faults and ensure the stability of the power system.
Power transmission and distribution system
Line protection: provides efficient protection for transmission lines to prevent widespread power outages caused by faults.
Segmented protection: Protecting and controlling each segment in the distribution system to improve the reliability of the distribution network.
Industrial power system
Motor protection: protects large motors and critical equipment in industrial power systems from production interruptions caused by faults.
Generator protection: provides comprehensive protection and monitoring for industrial power generation equipment to ensure the safe operation of the power generation system.
renewable energy
Wind farm protection: provides protection for substations and transmission lines in wind farms, ensuring the stability of the wind power system.
Photovoltaic power station protection: Monitor and protect key equipment in photovoltaic power stations to prevent faults from affecting power output.
summary
The Multilin F650BABF2G1HI6 digital protection controller provides reliable protection, control, and monitoring solutions for power systems, widely used in substations, transmission and distribution systems, industrial power systems, and renewable energy fields, ensuring the safety and stability of power systems.
2.產 品 展 示
