Multilin L90N02HKHF8LH6繼電器面板
1.產 品 資 料 介 紹：
中文資料：
Multilin L90N02HKHF8LH6 繼電器面板是 GE Multilin 系列中的一個組件，通常用于電力系統中的繼電器控制和保護。它在繼電器面板的配置和功能方面具有高性能的設計，提供了多種保護和控制選項。以下是該繼電器面板的詳細信息：
主要特點和功能
面板設計
- 結構堅固：面板通常由耐用的金屬材料制成，確保長期穩定運行。
- 模塊化配置：支持多種繼電器模塊的安裝和配置，方便用戶根據需要進行定制。
- 防護設計：具備防塵、防水等工業級防護設計，以保護內部繼電器和電路板免受環境影響。
保護功能
- 綜合保護：支持多種保護功能，包括過流保護、過壓保護、欠壓保護、接地故障保護等。
- 可編程功能：提供靈活的編程選項，允許用戶根據特定需求自定義保護邏輯和參數設置。
控制功能
- 斷路器控制：可以控制斷路器的操作，包括開關控制和自動重合閘功能。
- 自動化控制：支持自動化控制功能，如自動隔離故障、自動恢復供電等。
監測與診斷
- 實時監測：監控系統的電流、電壓、功率等實時數據，提供詳細的系統狀態信息。
- 事件記錄：記錄和存儲故障事件和操作日志，幫助進行故障排查和系統分析。
- 波形捕捉：捕捉電氣波形數據，進行深度分析以優化系統性能。
通信接口
- 協議支持：支持多種通信協議，如 Modbus、DNP3、IEC 61850 等，確保與其他系統和設備的兼容性。
- 接口選項：配備以太網、RS-232、RS-485 等接口，方便進行數據交換和系統集成。
用戶界面
- 顯示屏：通常配備 LCD 顯示屏，用于顯示系統狀態、參數設置和警報信息。
- 配置工具：提供圖形化配置工具，簡化用戶設置和系統管理過程。
高可靠性與環境適應性
- 工業級設計：符合工業級標準，適應各種嚴苛環境條件，確保長期穩定運行。
- 寬溫范圍：適應不同的環境溫度，保障系統的可靠性。
應用領域
變電站
- 設備保護：用于變電站中的設備保護和控制，確保變電站的安全和穩定運行。
- 系統集成：支持變電站內各種設備的集成和管理，提供全面的保護和控制解決方案。
配電系統
- 饋線管理：在配電系統中提供饋線保護和控制，優化系統性能。
- 故障隔離：實現有效的故障隔離，減少系統停電范圍，提高系統可靠性。
工業電力系統
- 關鍵設備保護：為工業電力系統中的關鍵設備提供保護，避免故障引發生產中斷。
- 電力監控：實時監控和管理工業電力系統的運行狀態，提高系統運行效率。
總結
Multilin L90N02HKHF8LH6 繼電器面板是一款功能強大的電力系統保護和控制組件，具有高性能的保護、控制、監測和通信能力。其模塊化設計、靈活的配置選項以及高可靠性使其在變電站、配電系統和工業電力系統中具有廣泛的應用價值。
英文資料：
The Multilin L90N02HKHF8LH6 relay panel is a component in the GE Multilin series, commonly used for relay control and protection in power systems. It has high-performance design in terms of relay panel configuration and functionality, providing multiple protection and control options. The following is the detailed information of the relay panel:
Main features and functions
Panel design
Sturdy structure: Panels are typically made of durable metal materials to ensure long-term stable operation.
Modular configuration: supports the installation and configuration of multiple relay modules, making it convenient for users to customize according to their needs.
Protection design: It has industrial grade protection design such as dust-proof and waterproof to protect internal relays and circuit boards from environmental influences.
Protection function
Comprehensive protection: supports multiple protection functions, including overcurrent protection, overvoltage protection, undervoltage protection, ground fault protection, etc.
Programmable function: Provides flexible programming options, allowing users to customize protection logic and parameter settings according to specific needs.
control function
Circuit breaker control: It can control the operation of circuit breakers, including switch control and automatic reclosing function.
Automated control: Supports automated control functions such as automatic fault isolation, automatic power restoration, etc.
Monitoring and Diagnosis
Real time monitoring: Monitor the real-time data of the system's current, voltage, power, etc., and provide detailed system status information.
Event recording: Record and store fault events and operation logs to assist in troubleshooting and system analysis.
Waveform capture: Capture electrical waveform data for in-depth analysis to optimize system performance.
communication interface
Protocol support: Supports multiple communication protocols such as Modbus, DNP3, IEC 61850, etc., ensuring compatibility with other systems and devices.
Interface options: Equipped with Ethernet, RS-232, RS-485 and other interfaces for convenient data exchange and system integration.
user interface
Display screen: usually equipped with an LCD display screen, used to display system status, parameter settings, and alarm information.
Configuration tool: Provides graphical configuration tools to simplify user settings and system management processes.
High reliability and environmental adaptability
Industrial grade design: meets industrial standards, adapts to various harsh environmental conditions, and ensures long-term stable operation.
Wide temperature range: Suitable for different environmental temperatures to ensure the reliability of the system.
application area
transformer substation
Equipment protection: used for equipment protection and control in substations, ensuring the safe and stable operation of substations.
System Integration: Supports the integration and management of various devices within the substation, providing comprehensive protection and control solutions.
Distribution system
Feedline management: Provide feeder protection and control in the distribution system to optimize system performance.
Fault isolation: achieve effective fault isolation, reduce the range of system power outages, and improve system reliability.
Industrial power system
Key equipment protection: provides protection for key equipment in industrial power systems to prevent production interruptions caused by faults.
Power monitoring: Real time monitoring and management of the operational status of industrial power systems to improve system efficiency.
summary
The Multilin L90N02HKHF8LH6 relay panel is a powerful power system protection and control component with high-performance protection, control, monitoring, and communication capabilities. Its modular design, flexible configuration options, and high reliability make it widely applicable in substations, distribution systems, and industrial power systems.
