Multilin 369-LO-R-0-0-E電機管理繼電器
1.產 品 資 料 介 紹：
中文資料：
Multilin 369-LO-R-0-0-E 電機管理繼電器 是 GE Multilin 系列中的一款先進的電機保護和管理設備，專為保護和管理電動機及其相關設備而設計。以下是關于 Multilin 369-LO-R-0-0-E 電機管理繼電器的詳細信息：
主要功能和特點
綜合電機保護：
- 過載保護：提供精確的電機過載保護，根據設定的過載曲線自動觸發報警或斷開電機。
- 欠壓和過壓保護：監測電機電壓，防止因電壓過低或過高而導致的設備損壞。
- 過熱保護：監測電機溫度，防止因過熱引發的故障，通過溫度傳感器或熱電偶實現。
故障檢測和報警：
- 失相保護：檢測電機的失相情況，防止因相序異常導致的電機損壞。
- 短路保護：監測電流異常，防止短路引發的故障。
- 振動監測：集成振動傳感器，檢測電機運行中的振動異常，避免機械故障。
高級控制和自動化：
- 自動重啟功能：在電機故障恢復后自動重啟，提高系統的自動化水平和恢復能力。
- 定時功能：支持定時啟動和停止，方便電機的周期性運行和維護。
通信和集成：
- 多種通信協議：支持多種通信協議如 Modbus、DNP3、IEC 61850，便于與 SCADA 系統和其他設備集成。
- 遠程監控：通過網絡實現遠程監控和控制，方便系統的管理和維護。
靈活配置和擴展：
- 模塊化設計：支持模塊化配置，用戶可以根據需求選擇不同的保護和控制模塊。
- 易于安裝和維護：提供標準化的安裝接口和清晰的標識，簡化了安裝和調試過程。
高可靠性和耐用性：
- 工業級設計：采用高質量工業級組件和材料，確保在各種惡劣環境下的長期穩定運行。
- 抗干擾能力：具備強大的電磁兼容性和抗干擾能力，確保信號傳輸?shù)姆€(wěn)定性和可靠性。
應用領域
電力配電系統：
- 電機保護：用于保護配電系統中的電動機，防止過載、短路、失相等故障，確保系統的安全和穩定。
- 控制系統：提供電動機的控制和自動化功能，提高配電系統的運行效率。
工業設施：
- 設備管理：在工業設施中用于管理和保護關鍵電動機，防止設備故障和停機，提升生產效率。
- 過程控制：集成在生產過程控制系統中，監測和控制電動機的運行狀態，優化生產過程。
變電站：
- 綜合保護解決方案：與變電站中的其他保護設備集成，提供全面的電動機保護和管理功能。
- 系統擴展：支持變電站系統的擴展和升級，靈活應對不同的應用需求。
智能電網：
- 智能監測和控制：在智能電網中集成多種監測和控制功能，提高電網的智能化水平和響應能力。
- 數據分析：支持?jǐn)?shù)據的實時處理和分析，優化電網的運行和維護。
結論
Multilin 369-LO-R-0-0-E 電機管理繼電器 作為 GE Multilin 系列中的一款高性能電機保護設備，通過其全面的保護功能、高級控制、靈活配置、可靠性和耐用性，為電力配電系統、工業設施、變電站和智能電網等領域提供了可靠和高效的解決方案。它在確保電動機和系統的安全、穩定和高效運行方面發揮了重要作用。
英文資料：
The Multilin 369-LO-R-0-0-E motor management relay is an advanced motor protection and management device in the GE Multilin series, designed specifically for protecting and managing electric motors and related equipment. The following is detailed information about the Multilin 369-LO-R-0-0-E motor management relay:
Main functions and features
Comprehensive motor protection:
Overload protection: Provides precise motor overload protection, automatically triggering an alarm or disconnecting the motor according to the set overload curve.
Undervoltage and Overvoltage Protection: Monitor motor voltage to prevent equipment damage caused by low or high voltage.
Overheating protection: Monitor motor temperature to prevent faults caused by overheating, achieved through temperature sensors or thermocouples.
Fault detection and alarm:
Phase loss protection: Detect the phase loss of the motor to prevent motor damage caused by abnormal phase sequence.
Short circuit protection: Monitor abnormal current to prevent faults caused by short circuits.
Vibration monitoring: Integrated vibration sensors to detect abnormal vibrations during motor operation and avoid mechanical failures.
Advanced control and automation:
Automatic restart function: Automatically restart after the motor fault is restored, improving the automation level and recovery capability of the system.
Timer function: Supports timed start and stop, facilitating the periodic operation and maintenance of the motor.
Communication and integration:
Multiple communication protocols: Supports multiple communication protocols such as Modbus, DNP3, IEC 61850, making it easy to integrate with SCADA systems and other devices.
Remote monitoring: Implementing remote monitoring and control through the network, facilitating system management and maintenance.
Flexible configuration and expansion:
Modular design: Supports modular configuration, allowing users to choose different protection and control modules according to their needs.
Easy to install and maintain: Provides standardized installation interfaces and clear labeling, simplifying the installation and debugging process.
High reliability and durability:
Industrial grade design: Using high-quality industrial grade components and materials to ensure long-term stable operation in various harsh environments.
Anti interference capability: It has strong electromagnetic compatibility and anti-interference ability, ensuring the stability and reliability of signal transmission.
application area
Power distribution system:
Motor protection: used to protect the electric motors in the distribution system, prevent overload, short circuit, and phase loss faults, and ensure the safety and stability of the system.
Control system: Provides control and automation functions for electric motors to improve the operational efficiency of the power distribution system.
Industrial facilities:
Equipment management: Used in industrial facilities to manage and protect critical motors, prevent equipment failures and shutdowns, and improve production efficiency.
Process control: integrated into the production process control system, monitoring and controlling the operating status of the electric motor to optimize the production process.
Substation:
Comprehensive protection solution: Integrated with other protection devices in the substation, providing comprehensive motor protection and management functions.
System Expansion: Supports the expansion and upgrade of substation systems, flexibly responding to different application needs.
Smart grid:
Intelligent monitoring and control: Integrating multiple monitoring and control functions in the smart grid to improve the level of intelligence and responsiveness of the power grid.
Data analysis: Support real-time processing and analysis of data to optimize the operation and maintenance of the power grid.
conclusion
The Multilin 369-LO-R-0-0-E motor management relay, as a high-performance motor protection device in the GE Multilin series, provides reliable and efficient solutions for power distribution systems, industrial facilities, substations, and smart grids through its comprehensive protection functions, advanced control, flexible configuration, reliability, and durability. It plays an important role in ensuring the safe, stable, and efficient operation of motors and systems.
2.產 品 展 示
