The 100% to 0% cycle repeats the number of calibration cycles
specified in <S9>. After recording the final 0% reading, the
actuator moves at the selected stroke time to the position
demand from the MFP module. When the calibration cycles are
complete, the actuator ramps to the position demand from the
MFP module if the IMHSS03 module is in the automatic tuning
mode. In manual tuning mode, the actuator ramps to its preca
libration position when the calibration cycles are complete.
Allow the cycle to complete. After completion of all cycles, the
calibrated differential voltages are written to HSS module
dual-port RAM.
6. Observe the module status output block N+6, bits 0 and 1.
The binary value of these bits is 0 while the LVDT calibration is
in progress. When the calibration is complete, these bits have a
binary value of 1.
If a binary 2 appears in the module status bits, then an error
has occurred during the calibration procedure. All outputs will
show bad quality and the HSS module will retain the previous
calibration values. The other error bits in the module status
output blocks N+6 and the LVDT status output blocks N+7 will
show which error has occurred. Refer to Section 6 and Table
6-5 for corrective action. After correcting the error, repeat the
calibration procedure.
NOTE: To clear the calibration error status and bad output qualities
without performing another calibration, set calibrate mode to dis
able, <S11> = 0.
