Multilin T60U03HKHF8NH6多線制繼電器
1.產 品 資 料 介 紹：
中文資料：
Multilin T60U03HKHF8NH6 多線制繼電器是 GE Multilin 系列的一款先進的繼電器，設計用于提供多功能電力保護和控制。它支持多線制（或多輸入）配置，適用于復雜的電力系統和工業應用。以下是該繼電器的主要應用領域及其功能：
主要功能：
多功能保護：
- 過電流保護：監測和保護設備免受過電流影響。
- 過電壓和欠電壓保護：確保電壓維持在安全范圍內。
- 頻率保護：監控系統頻率，防止頻率異常。
- 接地故障保護：檢測和響應接地故障，保護設備和系統的安全。
多線制配置：
- 支持多個輸入通道，適合復雜電力系統的保護和監控需求。
- 提供靈活的配置選項，滿足各種應用場景的需求。
通訊和集成：
- 支持多種通訊協議，如Modbus、DNP3、IEC 61850，便于與上位系統集成。
- 提供遠程監控和操作功能，方便用戶進行故障診斷和系統管理。
數據記錄和分析：
- 記錄和存儲事件日志和系統數據，幫助進行故障分析和性能評估。
- 提供圖形化的數據分析工具，支持用戶查看和分析電力系統狀態。
用戶界面和配置：
- 配備易于使用的界面，支持直觀的操作和配置。
- 提供詳細的配置選項，適應不同應用需求。
應用領域：
變電站保護：
- 母線保護：監測和保護變電站內的母線，防止母線故障擴散。
- 變壓器保護：為變壓器提供過電流、過電壓和接地故障保護。
- 斷路器保護：監控?cái)嗦菲鞯臓顟B(tài)和操作，確保斷路器可靠運行。
發電廠保護：
- 發電機保護：保護發電機免受過電流、過電壓、欠電壓和頻率異常影響。
- 發電機組保護：提供綜合保護，確保發電機組的安全穩定運行。
配電系統保護：
- 線路保護：提供過電流、短路和接地故障保護，確保配電線路的安全。
- 負荷管理：監控和管理配電網的負荷，防止過載和設備損壞。
工業設施保護：
- 工廠電力保護：監測和保護工廠內的電力系統，防止設備故障和生產中斷。
- 礦山和重工業：保護礦山設備和重工業設備，確保生產過程的安全性和連續性。
新能源發電：
- 風電場：監測和保護風電場的發電設備，確保風力發電的穩定性。
- 太陽能電站：為太陽能電站的設備提供過電流、過電壓和接地故障保護。
交通運輸：
- 鐵路系統：保護鐵路電力設備，確保鐵路系統的可靠運行。
- 地鐵和輕軌：提供地鐵和輕軌系統中的電力設備保護，確保安全運行。
英文資料：
The Multilin T60U03HHF8NH6 multi wire relay is an advanced relay in the GE Multilin series, designed to provide multifunctional power protection and control. It supports multi wire (or multi input) configuration, suitable for complex power systems and industrial applications. The following are the main application areas and functions of this relay:
Main functions:
Multi functional protection:
Overcurrent protection: Monitor and protect equipment from the effects of overcurrent.
Overvoltage and undervoltage protection: Ensure that the voltage is maintained within a safe range.
Frequency protection: Monitor the system frequency to prevent frequency anomalies.
Ground fault protection: detecting and responding to ground faults to protect the safety of equipment and systems.
Multi line configuration:
Supports multiple input channels, suitable for the protection and monitoring needs of complex power systems.
Provide flexible configuration options to meet the needs of various application scenarios.
Communication and integration:
Supports multiple communication protocols, such as Modbus, DNP3, IEC 61850, for easy integration with upper level systems.
Provide remote monitoring and operation functions to facilitate user fault diagnosis and system management.
Data recording and analysis:
Record and store event logs and system data to assist in fault analysis and performance evaluation.
Provide graphical data analysis tools to support users in viewing and analyzing the status of the power system.
User interface and configuration:
Equipped with an easy-to-use interface that supports intuitive operation and configuration.
Provide detailed configuration options to meet different application requirements.
Application areas:
Substation protection:
Busbar protection: Monitor and protect the busbars within the substation to prevent the spread of busbar faults.
Transformer protection: provides overcurrent, overvoltage, and ground fault protection for transformers.
Circuit breaker protection: Monitor the status and operation of the circuit breaker to ensure its reliable operation.
Power plant protection:
Generator protection: protects the generator from overcurrent, overvoltage, undervoltage, and frequency anomalies.
Generator protection: Provides comprehensive protection to ensure the safe and stable operation of the generator set.
Power distribution system protection:
Line protection: Provides overcurrent, short circuit, and ground fault protection to ensure the safety of distribution lines.
Load management: Monitor and manage the load of the distribution network to prevent overload and equipment damage.
Industrial facility protection:
Factory power protection: Monitor and protect the power system within the factory to prevent equipment failures and production interruptions.
Mining and heavy industry: Protect mining and heavy industry equipment to ensure the safety and continuity of the production process.
New energy generation:
Wind farm: Monitor and protect the power generation equipment of the wind farm to ensure the stability of wind power generation.
Solar power station: provides overcurrent, overvoltage, and ground fault protection for the equipment of the solar power station.
Transportation:
Railway system: Protect railway power equipment and ensure the reliable operation of the railway system.
Subway and Light Rail: Provide protection for electrical equipment in subway and light rail systems to ensure safe operation.
2.產 品 展 示
