MULTILIN F650BABF1G0LO饋線保護繼電器 PDF資料
1.產 品 資 料 介 紹：
中文資料：
MULTILIN F650BABF1G0LO 是 GE 的 MULTILIN 系列中的一款饋線保護繼電器，設計用于電力系統中的饋線保護和控制。以下是關于 F650BABF1G0LO 的詳細信息，包括其主要特性和應用領域：
主要特性和功能
保護功能：
- 過電流保護： 監測饋線的電流，提供過電流保護以防止過載和短路。
- 地漏電流保護： 監測地漏電流，防止由于絕緣故障導致的系統問題。
- 斷相保護： 檢測電源缺相或不平衡，防止因缺相對饋線造成的損害。
- 過電壓/欠電壓保護： 保護饋線免受電壓異常的影響。
監控與診斷：
- 實時監控： 提供實時的電流、電壓、功率等參數顯示，便于監控饋線的運行狀態。
- 故障記錄： 存儲故障事件和歷史數據，幫助分析和診斷系統問題。
- 性能分析： 提供詳細的系統性能數據，支持預防性維護和優化操作。
通信與集成：
- 通信協議： 支持常見的工業通信協議，如 Modbus、DNP3、IEC 61850，便于與其他控制系統集成。
- 遠程監控： 通過網絡接口支持遠程訪問、配置和監控，增強系統管理的便利性。
用戶界面：
- 顯示屏： 配備 LCD 顯示屏，用于實時顯示保護參數和系統狀態。
- 操作界面： 提供用戶友好的界面，方便設置和調整保護功能。
應用領域：
- 電力系統： 用于電力配電系統中的饋線保護，確保電力系統的穩定性和安全性。
- 工業自動化： 在工業環境中為饋線提供保護和監控，支持自動化控制系統。
- 發電和變電站： 適用于發電機組和變電站中的饋線保護和控制。
英文資料：
MULTILIN F650BABF1G0LO is a feeder protection relay in GE's MULTILIN series, designed for feeder protection and control in power systems. The following is detailed information about F650BABF1G0LO, including its main features and application areas:
Main features and functions
Protection function:
Overcurrent protection: Monitor the current of the feeder and provide overcurrent protection to prevent overload and short circuit.
Ground leakage current protection: Monitor ground leakage current to prevent system problems caused by insulation faults.
Phase loss protection: detects power supply phase loss or imbalance to prevent damage to the feeder caused by phase loss.
Overvoltage/undervoltage protection: protects the feeder from the impact of abnormal voltage.
Monitoring and Diagnosis:
Real time monitoring: Provides real-time display of parameters such as current, voltage, and power, making it easy to monitor the operating status of feeders.
Fault records: Store fault events and historical data to assist in analyzing and diagnosing system issues.
Performance analysis: Provide detailed system performance data to support preventive maintenance and optimization operations.
Communication and Integration:
Communication Protocol: Supports common industrial communication protocols such as Modbus, DNP3, IEC 61850, making it easy to integrate with other control systems.
Remote monitoring: Supports remote access, configuration, and monitoring through network interfaces, enhancing the convenience of system management.
User interface:
Display screen: Equipped with an LCD display screen for real-time display of protection parameters and system status.
Operation interface: Provides a user-friendly interface for easy setting and adjustment of protection functions.
Application areas:
Power system: used for feeder protection in power distribution systems to ensure the stability and safety of the power system.
Industrial automation: providing protection and monitoring for feeders in industrial environments, supporting automation control systems.
Power generation and substations: suitable for feeder protection and control in generator sets and substations.
2.產 品 展 示
