MULTILIN EP5P5B5HRR電機保護系統 PDF資料
1.產 品 資 料 介 紹：
中文資料：
ultilin EP5P5B5HRR 是 GE 的 Multilin 系列中的一款電機保護系統，旨在為電機提供全面的保護和控制功能。以下是關于 Multilin EP5P5B5HRR 電機保護系統的詳細信息：
主要特性和功能
電機保護功能：
- 過載保護： 實時監控電機的電流，防止過載情況導致的電機損壞。
- 堵轉保護： 檢測電機啟動時的堵轉情況，提供保護以防止電機損壞。
- 斷相保護： 檢測電源缺相或不平衡情況，防止因缺相對電機造成的損壞。
- 過電壓/欠電壓保護： 保護電機免受電壓波動的影響。
- 短路保護： 監測異常電流情況，提供短路保護以防止電機受損。
- 熱保護： 通過溫度監測防止電機過熱，保護電機的正常運行。
- 地漏電流保護： 監測并保護因絕緣故障引起的地漏電流問題。
監控與診斷：
- 實時監控： 提供實時的電流、電壓、功率和其他關鍵參數的監控。
- 故障診斷： 記錄故障事件并提供詳細的診斷信息，幫助快速定位和解決問題。
- 數據記錄： 存儲歷史數據和事件記錄，便于后續分析和審計。
通信與集成：
- 通信協議： 支持多種工業標準通信協議，如 Modbus RTU、Modbus TCP/IP、DNP3 和 IEC 61850，便于與其他控制系統集成。
- 遠程監控： 通過通信接口支持遠程訪問和監控，簡化維護和管理工作。
用戶界面：
- 顯示屏： 配備 LCD 顯示屏，用于實時顯示電機的運行狀態和參數。
- 操作界面： 友好的用戶界面，方便進行設置和調整。
- 可編程性： 提供可編程的輸入/輸出選項，以滿足特定應用需求。
擴展功能：
- 多種保護算法： 提供多種保護算法，適應不同類型電機的保護需求。
- 靈活配置： 可根據具體應用需求進行配置，確保系統的靈活性和可擴展性。
應用領域
- 工業自動化： 在各種工業環境中用于電機的保護和控制，確保設備的可靠運行。
- 發電和配電系統： 適用于發電機組和配電系統中的電機保護和監控。
- 水處理和泵站： 用于水處理設施和泵站中的電機保護，防止因故障導致的設備停機和損壞。
英文資料：
The ultilin EP5P5B5HRR is a motor protection system in GE's Multilin series, designed to provide comprehensive protection and control functions for motors. The following is detailed information about the Multilin EP5P5B5HRR motor protection system:
Main features and functions
Motor protection function:
Overload protection: Real time monitoring of motor current to prevent motor damage caused by overload situations.
Blocked rotor protection: detects the blockage of the motor during startup and provides protection to prevent motor damage.
Phase loss protection: detects power supply phase loss or imbalance to prevent damage to the motor caused by phase loss.
Overvoltage/undervoltage protection: protects the motor from voltage fluctuations.
Short circuit protection: Monitor abnormal current conditions and provide short circuit protection to prevent motor damage.
Thermal protection: Prevent motor overheating through temperature monitoring and ensure the normal operation of the motor.
Ground leakage current protection: Monitor and protect against ground leakage current issues caused by insulation faults.
Monitoring and Diagnosis:
Real time monitoring: Provides real-time monitoring of current, voltage, power, and other key parameters.
Fault diagnosis: Record fault events and provide detailed diagnostic information to help quickly locate and solve problems.
Data recording: Store historical data and event records for subsequent analysis and auditing.
Communication and Integration:
Communication Protocol: Supports multiple industrial standard communication protocols, such as Modbus RTU, Modbus TCP/IP, DNP3, and IEC 61850, making it easy to integrate with other control systems.
Remote monitoring: Supports remote access and monitoring through communication interfaces, simplifying maintenance and management work.
User interface:
Display screen: Equipped with an LCD display screen for real-time display of the motor's operating status and parameters.
Operating Interface: A user-friendly interface that facilitates settings and adjustments.
Programmable: Provides programmable input/output options to meet specific application requirements.
Extended functions:
Multiple protection algorithms: Provide multiple protection algorithms to meet the protection needs of different types of motors.
Flexible configuration: It can be configured according to specific application requirements to ensure the flexibility and scalability of the system.
application area
Industrial automation: Used for motor protection and control in various industrial environments to ensure reliable operation of equipment.
Power generation and distribution system: suitable for motor protection and monitoring in generator sets and distribution systems.
Water treatment and pumping stations: used for motor protection in water treatment facilities and pumping stations to prevent equipment shutdown and damage caused by malfunctions.
2.產 品 展 示
3.其他產品
