Multilin 750-P1-G1-S1-H電源管理 PDF資料
1.產 品 資 料 介 紹：
中文資料：
Multilin 750-P1-G1-S1-H 是 GE Multilin 提供的一款電源管理系統，旨在優化和保護電力系統中的電源分配。此系統提供了全面的電源監控、保護和控制功能，適用于各種工業和商業電力應用。以下是 Multilin 750-P1-G1-S1-H 電源管理系統的主要特點和應用領域：
主要特點：
電源監控：
- 實時數據：提供實時的電壓、電流、功率和功率因數等電源參數監控，幫助用戶了解電力系統的運行狀態。
- 電能質量分析：監測和分析電能質量，包括諧波、閃變、頻率波動等，確保電力系統的穩定性。
保護功能：
- 過載保護：在電流超出設定值時自動切斷電源，防止電氣設備過載。
- 短路保護：提供短路故障檢測和斷路功能，確保系統在發生短路時能夠迅速斷開電源。
- 欠電壓和過電壓保護：監控電壓水平，并在出現欠電壓或過電壓情況時觸發警報或斷開電源。
控制功能：
- 開關控制：能夠遠程控制電源開關，方便進行系統切換和故障排查。
- 自動重啟：在系統恢復正常后自動重啟，減少人工干預的需求。
通信能力：
- 通訊協議支持：支持常見的通訊協議，如 Modbus、DNP3、Ethernet/IP 等，方便與其他監控和控制系統的集成。
- 遠程監控：提供遠程訪問功能，通過網絡接口實現數據監控和系統控制。
用戶界面：
- 顯示屏：配備顯示屏，顯示電源參數、狀態信息和故障報警，便于現場操作和數據查看。
- 操作簡便：用戶界面設計直觀，易于配置和操作，提供快捷的設置和調整選項。
高可靠性：
- 工業級設計：設計用于工業環境，具備高可靠性和耐用性，能夠在各種工作條件下穩定運行。
- 抗干擾能力：具有良好的抗電磁干擾能力，確保測量數據和系統操作的準確性。
數據記錄與分析：
- 歷史數據記錄：能夠存儲歷史數據和事件日志，支持后續分析和報告生成。
- 故障診斷：提供詳細的故障記錄和診斷功能，幫助識別和排除電力系統中的問題。
英文資料：
Multilin 750-P1-G1-S1-H is a power management system provided by GE Multilin, designed to optimize and protect power distribution in the power system. This system provides comprehensive power monitoring, protection, and control functions, suitable for various industrial and commercial power applications. The following are the main features and application areas of the Multilin 750-P1-G1-S1-H power management system:
Main features:
Power monitoring:
Real time data: Provides real-time monitoring of power parameters such as voltage, current, power, and power factor to help users understand the operating status of the power system.
Power quality analysis: Monitor and analyze power quality, including harmonics, flicker, frequency fluctuations, etc., to ensure the stability of the power system.
Protection function:
Overload protection: Automatically cuts off the power supply when the current exceeds the set value to prevent electrical equipment from overloading.
Short circuit protection: Provides short circuit fault detection and circuit breaking functions to ensure that the system can quickly disconnect the power supply in the event of a short circuit.
Undervoltage and Overvoltage Protection: Monitor voltage levels and trigger alarms or disconnect power in the event of undervoltage or overvoltage conditions.
Control function:
Switch control: It can remotely control the power switch, facilitating system switching and troubleshooting.
Automatic restart: Automatically restart after the system returns to normal, reducing the need for manual intervention.
Communication ability:
Communication protocol support: Supports common communication protocols such as Modbus, DNP3, Ethernet/IP, etc., facilitating integration with other monitoring and control systems.
Remote monitoring: Provides remote access functionality, enabling data monitoring and system control through network interfaces.
User interface:
Display screen: Equipped with a display screen, it displays power parameters, status information, and fault alarms for easy on-site operation and data viewing.
Easy to operate: The user interface design is intuitive, easy to configure and operate, and provides quick settings and adjustment options.
High reliability:
Industrial grade design: designed for industrial environments, with high reliability and durability, capable of stable operation under various working conditions.
Anti interference ability: It has good anti electromagnetic interference ability to ensure the accuracy of measurement data and system operation.
Data recording and analysis:
Historical data recording: capable of storing historical data and event logs, supporting subsequent analysis and report generation.
Fault diagnosis: Provide detailed fault records and diagnostic functions to help identify and troubleshoot problems in the power system.
2.產 品 展 示
