IMHSS03 fails to
calibrate and there
are no configuration
or installation errors.
Process
hardware.
Check the process hardware.
LVDT calibration
fails.
LVDT 100%
voltage less
than LVDT 0%
voltage.
Check LVDT connection. Replace LVDT.
Cannot tune
demodulator gain.
Primary oscilla
tor amplitude.
Adjust amplitude of primary oscillator.
No servo drive from
the servo amplifiers.
Bad connection
to the servo
valve, defective
servo valve.
Check the servo valve.
1. Connect an oscilloscope to the servo valve at the appropriate
termination unit or module terminals (SERVO_C_). Connect the
oscilloscope probes differentially across the + and – terminals of
the servo output. Check the servo outputs by doing Steps 2
through 4. Repeat the procedure for each bad servo output.
2. Enter a position demand to change the actuator position.
3. Verify that there is a servo drive and return signal for each servo
output.
4. If there is no servo valve drive signal or return signal, check the
continuity of the connecting cables.
