NW-BM85C002模塊,NW-BM85C002使用配置教程
雙列直插式開關和跳線設置，以及工作LED狀態。
表A-1至A-5列出了以下人員選擇的操作選項：設置IMHSS03雙列直插式開關。表A-6列出了操作通過設置跳線選擇的選項。表A-7列出了IMHSS03LED狀態。
IMHSS03雙列直插式開關和跳線設置表A-2列出了解調器增益設置。表A-3列出了控制器增益設置。這些表中的增益值適用于功能代碼為150的模塊。對于增益值
NW-BM85C002模塊使用功能55的模塊，請參閱功能代碼應用手冊。使用函數啟動解調器調諧代碼55，將解調器增益（雙列直插式開關S2）設置為2。到使用功能代碼55啟動控制器調諧，將控制增益（雙列直插式開關S3）設置為1。附錄B涵蓋了IMHSS03校準程序，使用功能代碼150，模擬控制回路調諧理論和控制器增益調節程序。完成本節中的步驟
附錄確保渦輪機節流閥的準確定位閥門和最佳頻率響應。完成在操作液壓伺服模塊（HSS）之前，請執行本附錄中的步驟。
INTRODUCTION
Appendix A contains a quick reference guide of IMHSS03
dipswitch and jumper settings, and operating LED states.
Tables A-1 through A-5 list the operating options selected by
setting the IMHSS03 dipswitches. Table A-6 lists operating
options selected by setting jumpers. Table A-7 lists IMHSS03
LED states.
IMHSS03 DIPSWITCH AND JUMPER SETTINGS
Table A-2 lists demodulator gain settings. Table A-3 lists controller gain settings. The gain values in these tables apply to
modules configured with function code 150. For gain values of
modules using function 55, refer to the Function Code Application Manual. To start demodulator tuning using function
code 55, set the demodulator gain (dipswitch S2) to two. To
start controller tuning using function code 55, set the controller gain (dipswitch S3) to one.Appendix B covers the IMHSS03 calibration procedure using
function code 150, analog control loop tuning theory and the
controller gain tuning procedure. Completing the steps in this
appendix insures accurate positioning of the turbine throttle
valve and the best possible frequency response. Complete the
steps in this appendix before placing the hydraulic servo module (HSS) in operation.
