KJ2005X1-MQ1卡件,KJ2005X1-MQ1怎么使用
附錄D是NIDI01輸入/輸出終端的快速參考
分配、跳線設置、電路板布局和電纜連接。參見數字輸入端接模塊（NIDI01）更多信息說明。
圖D-1顯示了NIDI01電路板布局和所需的跳線設置。圖D-2顯示了終端分配
和輸入/輸出信號極性。圖D-3顯示了終端電纜
KJ2005X1-MQ1卡件連接。IMHSS03模塊可以使用NTDI01數字輸入/輸出終端單元來終止其輸入/輸出連接，但只有
IMHSS02功能。NTDI01終端裝置沒有支持IMHSS03模塊的其他功能。終端裝置上的Dip分流器配置輸入/輸出信號。這個IMHSS03模塊有四個模擬輸入，九個模擬輸出，
三個數字輸入和一個數字輸出終止于NTDI01終端裝置。
快速參考附錄E是NTDI01輸入/輸出終端的快速參考分配、雙工分流設置、電路板布局和電纜連接。參見數字輸入終端裝置（NTDI01）說明了解更多信息。圖E-1顯示了NTDI01電路板布局。表E-1列出分流設置。圖E-2顯示了終端
The IMHSS03 module can use an NTDI01 Digital I/O Termina
tion Unit to terminate its I/O connections, but will only have
IMHSS02 functionality. The NTDI01 termination unit does not
support the additional features of the IMHSS03 module. Dip
shunts on the termination unit configure the I/O signals. The
IMHSS03 module has four analog inputs, nine analog outputs,
three digital inputs and one digital output that terminate at
the NTDI01 termination unit.
QUICK REFERENCE
Appendix E serves as a quick reference of NTDI01 I/O terminal
assignments, dipshunt settings, circuit board layout and cable
connections. Refer to the Digital Input Termination Unit
(NTDI01) instruction for more information.
Figure E-1 shows the NTDI01 circuit board layout. Table E-1
lists dipshunt settings. Figure E-2 shows the terminal
