增加設備故障。對于GMR PLC必須發出GMR輸入/輸出重置命令（%M12258）以恢復使用這些輸入通道。4.VersaMax GNIU的熱拆卸和熱插入不適用被允許嘗試熱插拔GNIU可能會導致
干擾GNIU和其他設備之間的背板傳輸并且可能導致GNIU的診斷測試聲明錯誤。這可能會導致電站中的其他模塊被標記為故障，也可能導致整個輸入站下線。對于需要安裝VersaMax GNIU的情況更換后，系統的操作程序必須要求操作員在嘗試之前切斷GNIU的電源修理
DEIF LSU-113DG負荷分配器5、關閉整個VersaMax工作站將導致系統暫時失去該站中的所有模擬通道（最多60個），而不是僅與正在更換的模塊相關的通道。如果冗余VersaMax輸入站可用，則程序可以選擇允許整個系統繼續運行短時間內輸入通道冗余的降級水平正在修復出現故障的輸入站。
操作說明：概述1、在智能輸入/輸出模塊上執行固件升級時在Genius NIU站，主機控制器必須處于停機狀態模式，或者必須從NIU上卸下Genius網絡電纜。
報錯 筆記拼
Addition of Device fault. For the case of a GMR PLC, an operator
must issue a GMR I/O Reset command (%M12258) to recover the
use of those input channels.
4. Hot Removal and Hot Insertion of the VersaMax GNIU is not
permitted. Attempting to hot insert or hot remove the GNIU may
interfere with backplane transfers between the GNIU and other
modules in the station, and can cause the GNIU’s diagnostic tests
to declare an error. That can cause other modules in the station to
be marked as faulted, and may also cause the entire input station to
go offline. For cases where a VersaMax GNIU needs to be
replaced, the system’s operating procedures must require the
operator to remove power from the GNIU before attempting the
repair.
5. Powering down the entire VersaMax station will cause the system
to temporarily lose all analog channels (up to 60) in that station, not
just the channels associated with the module that is being replaced.
If a redundant VersaMax Input Station is available, the procedures
may optionally allow the overall system to continue to operate with
a degraded level of input channel redundancy for a short time while
the faulted input station is being repaired.
Operating Notes: General
1. When performing a firmware upgrade on an intelligent I/O module
in the Genius NIU station, the host controller must be put into Stop
mode, or the Genius network cable must be removed from the NIU.
