PROSOFT MVI56-MBP 可編程邏輯控制系統 PDF資料
1.產 品 資 料 介 紹：
中文資料：
ProSoft MVI56-MBP 是一款用于 Allen-Bradley 控制器的可編程邏輯控制系統模塊，專為 Modbus 協議設計。以下是該模塊的主要特性、功能和應用領域：
主要特性
Modbus 通信：MVI56-MBP 主要支持 Modbus RTU 和 Modbus ASCII 協議，適用于需要與 Modbus 設備進行通信的應用。
集成式模塊：作為 Allen-Bradley ControlLogix 系列 PLC 的擴展模塊，它可以無縫集成到現有的控制系統中，增強系統的通信能力。
靈活的配置：模塊允許通過 ProSoft Configuration Builder (PCB) 工具進行配置。PCB 提供了圖形化界面，簡化了配置過程，支持多種 Modbus 設備的設置。
數據處理能力：支持高達 32 個 Modbus 連接，能夠處理大量的 I/O 數據，適合大規模應用。
實時數據交換：模塊支持快速的數據交換，確保實時處理和反饋，適合高速和要求高可靠性的應用場景。
診斷功能：提供實時診斷功能，能夠監測通信狀態和錯誤，并幫助排除故障。
擴展性：通過與其他 ProSoft 模塊的兼容性，可以實現更復雜的通信解決方案，滿足不同應用需求。
功能
- 數據讀寫：能夠從 Modbus 設備中讀取數據或向其寫入數據，實現與外部設備的有效數據交換。
- 數據映射：支持將 Modbus 數據映射到 PLC 內部的寄存器或標簽，實現與 PLC 程序的直接交互。
- 設備通訊：能夠與多種 Modbus 設備進行通信，包括傳感器、執行器、計量設備等。
- 狀態監控：提供實時的狀態監控和報警功能，確保系統穩定運行。
應用領域
工業自動化：在自動化控制系統中，MVI56-MBP 可用于與各種 Modbus 設備進行通信，提升系統集成能力和控制精度。
生產線監控：在生產線中，通過 Modbus 協議與傳感器和執行器進行數據交換，實現生產過程的監控和優化。
數據采集：用于從現場設備采集數據，并將數據傳送到控制系統，實現數據的集中管理和分析。
設備控制：通過與 Modbus 設備的通信，控制各種工業設備的運行狀態，如開關、速度調節等。
系統集成：適用于將 Modbus 設備集成到現有的 ControlLogix 控制系統中，擴展系統功能和通信能力。
英文資料：
ProSoft MVI56-MBP is a programmable logic control system module designed specifically for the Modbus protocol for Allen Bradley controllers. The following are the main features, functions, and application areas of this module:
Main characteristics
Modbus Communication: MVI56-MBP mainly supports Modbus RTU and Modbus ASCII protocols, suitable for applications that require communication with Modbus devices.
Integrated module: As an extension module of Allen Bradley ControlLogix series PLC, it can be seamlessly integrated into existing control systems, enhancing the system's communication capabilities.
Flexible configuration: The module allows configuration through the ProSoft Configuration Builder (PCB) tool. PCB provides a graphical interface, simplifies the configuration process, and supports the setup of multiple Modbus devices.
Data processing capability: Supports up to 32 Modbus connections, capable of processing large amounts of I/O data, suitable for large-scale applications.
Real time data exchange: The module supports fast data exchange, ensuring real-time processing and feedback, suitable for high-speed and high reliability application scenarios.
Diagnostic function: Provides real-time diagnostic function, can monitor communication status and errors, and help troubleshoot.
Scalability: Through compatibility with other ProSoft modules, more complex communication solutions can be implemented to meet different application requirements.
function
Data read-write: capable of reading data from or writing data to Modbus devices, enabling effective data exchange with external devices.
Data Mapping: Supports mapping Modbus data to registers or tags within the PLC, enabling direct interaction with the PLC program.
Device communication: capable of communicating with various Modbus devices, including sensors, actuators, measuring devices, etc.
Status monitoring: Provides real-time status monitoring and alarm functions to ensure stable system operation.
application area
Industrial Automation: In automation control systems, MVI56-MBP can be used to communicate with various Modbus devices, enhancing system integration capabilities and control accuracy.
Production line monitoring: In the production line, data exchange is carried out with sensors and actuators through Modbus protocol to achieve monitoring and optimization of the production process.
Data collection: used to collect data from on-site devices and transmit it to the control system to achieve centralized management and analysis of data.
Device control: By communicating with Modbus devices, control the operating status of various industrial equipment, such as switches, speed regulation, etc.
System Integration: Suitable for integrating Modbus devices into existing ControlLogix control systems, expanding system functionality and communication capabilities.
2.產 品 展 示
