IS220PPROS1B通用電氣卡件,IS220PPROS1B中文使用說明
執行快速設置（僅適用于一卷或兩卷）快速設置引導您通過最少的步驟來設置張力電子設備。要求您回答一些問題并輸入所需的值。這些選擇和必須進行參數設置，以準備張力電子設備進行測量。在快速設置中僅設置有限數量的選擇和參數設置。所有其他參數設置為出廠默認值。見附錄A.5出廠默認設置。
IS220PPROS1B通用電氣卡件快速設置可以通過兩種方式完成，具體取決于包裹增益的設置方式。包裹增益可以通過選擇“HangWeight”或“EnterWrapGain”來設置。?使用吊重，見第3.8.1節。?使用包裹增益，見第3.8.2節。第3.12.6節解釋了懸掛重量和包裹增益。檢查稱重傳感器信號極性這是一種檢查稱重傳感器是否連接以提供正輸出的簡單方法張力電子裝置的信號變化導致卷筒紙張力增加。1.用手推動，在一個負載上施加與增加的腹板張力相對應的力（盡可能靠近稱重傳感器）并檢查顯示讀數是否正確積極樂觀的如果顯示讀數為負值，則將稱重傳感器信號連接反向至張力電子設備。注釋如果不知道力的作用方向：–以相同的力方向連接稱重傳感器A和B。–以相同的力方向連接稱重傳感器C和D。要改變稱重傳感器A的極性，請反轉X3:1和2（A+和A-）。要改變稱重傳感器B的極性，請反轉X3:3和4（在B+和B-）要改變稱重傳感器C的極性，請反轉X3:5和6（C+和C-）。要改變稱重傳感器D的極性，請反轉X3:7和8（在D+和D-）。2、在改變稱重傳感器極性后，檢查顯示屏讀數是否為正值腹板張力。Performing a Fast Setup (Only for One or Two Rolls)
The fast setup guides you through a minimum number of steps to set up the tension electronics.
You are asked to answer some questions and to enter desired values. These selections and
parameter settings must be made to prepare the tension electronics for measurement.
Only a limited number of selections and parameter settings are set in fast setup. All other
parameters are set as factory default values. See Appendix A.5 Factory Default Settings.
Fast setup can be done in two ways, depending on how the wrap gain is set.
The wrap gain can be set by selecting “HangWeight” or “EnterWrapGain”.
? Using Hanging Weights, see Section 3.8.1.
? Using Wrap Gain, see Section 3.8.2.
Hanging Weights and Wrap Gain are explained in Section 3.12.6. Checking Load Cell Signal Polarity
This is a simple method to check that the load cells are connected to give a positive output
signal change from the tension electronics for increased web tension.
1. Push with your hand to apply a force corresponding to increased web tension on one load
cell at a time (as close to the load cell as possible) and check if the display reading is
positive. If the display reading is negative, invert the load cell signal connection to the
tension electronics.
NOTE
If you don’t know in which direction the force is acting:
– Connect load cells A and B with the same force direction.
– Connect load cells C and D with the same force direction.
To change the polarity of load cell A, invert X3:1 and 2 (In A+ and In A-).
To change the polarity of load cell B, invert X3:3 and 4 (In B+ and In B-).
To change the polarity of load cell C, invert X3:5 and 6 (In C+ and In C-).
