PM3328B-6-1-3-E模塊,PIONEER MAGNETICS使用參數
僅當選定的稱重傳感器組合設置為時，菜單SRSF才可用分段滾動。分段滾動比例因子（SRSF）用于補償總測量張力和當并非所有輥都由分段式稱重傳感器支撐時，給出總張力的估計值滾動應用。有關SRSF的計算，請參閱附錄A.3分段滾動比例因子（SRSF）。3.12.2.1包裹增益調度增益調度允許在一個測量輥上使用兩個不同的卷筒路徑。
PM3328B-6-1-3-E模塊可以設置包裹增益的兩個預定義值。包裹增益1用于包裹角度1，包裹增益2用于包裹角度2。要使用的兩個包絡增益中的哪一個是通過數字輸入信號或via選擇的現場總線。對于稱重傳感器組合，兩輥增益調度僅適用于第1輥。如果數字輸入設置為“0”，或者如果Profibus設置為“0”。如果數字輸入設置為“1”，或者如果Profibus設置為“1”。如果數字輸入用于包絡增益調度，則Profibus中的包絡增益調度字段為如果數字輸入用于遠程零設置或設置為“關”，則控制包裹增益調度來自Profibus。使用上下鍵從列表中選擇對象類型[ZZ]。1.StandardRoll（兩個稱重傳感器，A和B連接）2.SingleSideA（僅稱重傳感器A連接）3.SingleSideB（僅連接稱重傳感器B）當選擇單側測量時，測量信號乘以2和在顯示器和模擬輸出上顯示為卷筒紙張力。The menu SRSF will only be available when the selected load cell combination is set to
segmented roll.
Segmented Roll Scale Factor (SRSF) is used to compensate the total measured tension and
present an estimate of total tension when not all rolls are supported by load cells in a segmented
roll application. For calculations of SRSF, refer to Appendix A.3 Segmented Roll Scale Factor
(SRSF).
3.12.2.1 Wrap Gain Scheduling
Gain scheduling enables the use of two different web paths on one measuring roll. Two predefined values for wrap gain can be set.
Wrap gain 1 is used for wrap angle 1 and wrap gain 2 for wrap angle 2.
Which of the two wrap gains that is to be used is selected with a digital input signal or via
Profibus.
For load cell combination TwoRolls gain scheduling is available only for Roll 1.
Wrap gain parameter 1 is used if the digital input is set to “0”, or if the specified field in
Profibus is set to “0”.
Wrap gain parameter 2 is used if the digital input is set to “1”, or if the specified field in
Profibus is set to “1”.
If the digital input is used for wrap gain scheduling the wrap gain scheduling field in Profibus is
disabled.
If the digital input is used for remote zero set or set to “Off”, wrap gain scheduling is controlled
from Profibus.Use up and down keys to select type of object [ZZ] from list.
1. StandardRoll (two load cells, A and B connected)
2. SingleSideA (only load cell A connected)
3. SingleSideB (only load cell B connected)
