標稱負載Fnom是稱重傳感器的負載尺寸和校準，即靜態測量中的負載和最大測量負載方向Fext=擴展范圍。在Fnom和Fext之間測量精度可能會下降。靈敏度定義為輸出信號的差異在標稱負載和空載之間。精度等級定義為最大偏差，以及表示為標稱條件下靈敏度的百分比負載這包括線性偏差、滯后和重復性誤差。線性偏差是與在0和0的輸出值之間繪制的直線標稱負載，
IS200TDBTH6ACD燃機模塊與標稱負載相關。滯后是在以下條件下輸出信號的最大偏差：從零到標稱負載的循環中的相同負載，以及回到零，與標稱負載下的靈敏度有關。磁滯與周期成正比。重復性誤差定義為最大偏差在相同條件下的重復讀數之間。它表示為以下條件下靈敏度的百分比：標稱負載。溫度依賴性是與溫度相關的以%/K為單位的漂移標稱負載下的靈敏度。零點漂移定義為輸出信號中的漂移當稱重傳感器上沒有負載時。靈敏度漂移定義為在以下條件下輸出信號的漂移：標稱負載，不包括零點漂移。分段滾動比例因子（SRSF）是一個當稱重傳感器未安裝在以下位置時，補償包裹增益：每個支持分段滾動應用。Nominal load, Fnom, is the load for which the load cell is
dimensioned and calibrated, i.e. the sum of the stationary
load and the maximum measured load in the measuring
direction.
Fext = Extended range. Between Fnom and Fext some
decline in measurement accuracy may be experienced.
Sensitivity is defined as the difference in output signal
between nominal load and no load.
Accuracy class is defined as the maximum deviation, and
is expressed as a percentage of the sensitivity at nominal
load. This includes linearity deviation, hysteresis and
repeatability error.
Linearity deviation is the maximum deviation from a
straight line drawn between the output values of zero and
nominal load, related to the nominal load.
Hysteresis is the maximum deviation of the output signal at
the same load during a cycle from zero to nominal load and
back to zero, related to the sensitivity at nominal load.
The hysteresis is proportional to the cycle.
Repeatability error is defined as the maximum deviation
between repeated readings under identical conditions.
It is expressed as a percentage of the sensitivity at
nominal load.
Temperature dependence is the drift in %/K related to the
sensitivity at nominal load.
Zero point drift is defined as the drift in the output signal
when there is no load on the load cell.
Sensitivity drift is defined as the drift in the output signal at
nominal load, excluding the zero point drift.
Segmented Roll Scale Factor (SRSF) is a factor that
compensates Wrap Gain when load cells are not installed at
each support in segmented roll applications.
