第二個引用地址字段包含%I數據的引用地址。這個地址指向%I內存中的位置，其中包含來自模塊的狀態信息開始。您可以通過編輯來選擇報告給PLC的%I狀態位置的數量%I大小字段中的值。輸入報告給PLC的%I個位置的數量。選項有8、16、24、32或40。數據以以下格式返回：
前八個%I位置：（適用于%I大小值8、16、24、32和40Range選擇輸入范圍的類型和范圍。選擇為4-20mA、*0-20mA或4-20mA+。
BENTLY 9200-06-02-10-00監測器在4到20mA的默認范圍內，從4到20mA的輸入電流值報告0到32000個整數CPU的值。在0至20mA范圍內，輸入電流值范圍為0至20mA在0到20mA的輸入電流范圍內向CPU報告0到32000個整數值。增強的4至20mA范圍與默認的4至20mA范圍類似，但負值為當輸入電流降至4mA以下時報告。在此模式下，如果輸入0mA，報告給PLC的值為–8000。低報警輸入一個值，使低報警指示傳遞給PLC。每個通道都有下限報警值（報警下限），導致設置%I點。輸入的值假設無符號為正。應進行值檢查以確定是否在適當范圍內允許報警低值。允許的值為： 4至20mA范圍=0至32759 0至20mA范圍=0至32759 4至20mA+范圍=–8000至+32759報警高輸入一個值，使報警高指示傳遞給PLC。每個通道都有一個上限報警值（報警高），導致設置%I點。不帶符號輸入的值假設為要積極。應進行值檢查，以確定適當范圍內允許報警高值。允許的值為： 4至20mA范圍=1至32760 0至20mA范圍=1至32760 4至20mA+范圍=–7999至32760
Address
The second Reference Address field contains the reference address for %I data. The
address points to the location in %I memory where status information from the module
begins. You can select the number of %I status locations reported to the PLC by editing
the value in the %I Size field.
Enter the number of %I locations reported to the PLC. Choices are 8, 16, 24, 32, or 40.
The data is brought back in the following format:
First eight %I locations: (available for %I SIZE values 8, 16, 24, 32, and 40Range Select the type of input range and the ranges. Choices are 4 -20mA,* 0-20mA, or 4-20mA+.
In the 4 to 20mA default range, input current values ranging from 4 to 20mA report 0 to 32,000 integer
values to the CPU. In the 0 to 20mA range, input current values ranging from 0 to
20mA report 0 to 32,000 integer values to the CPU over an input current range of 0 to 20mA.
The enhanced 4 to 20mA range operates like the default 4 to 20mA range, except that negative values are
reported when the input current drops below 4mA. In this mode, if 0mA is input,
the value reported to the PLC is –8,000.
Alarm Low Enter a value that causes an alarm low indication to be passed to the PLC. Each channel has
a low limit alarm value (ALARM LO), which causes %I points to be set. Values entered
without a sign are assumed to be positive. Value checking should be done to determine if
the alarm low values are allowed for the appropriate range. The values allowed are:
4 to 20mA Range = 0 to 32759
0 to 20mA Range = 0 to 32759
4 to 20mA+ Range = –8,000 to +32759
Alarm High Enter a value that causes an alarm high indication to be passed to the PLC. Each channel has a high limit
alarm value (ALARM HI), which causes %I points to be set. Values entered without a sign are assumed to
be positive. Value checking should be done to determine if the
alarm high values are allowed for the appropriate range. The values allowed are:
4 to 20mA Range = 1 to 32760
0 to 20mA Range = 1 to 32760
4 to 20mA+ Range = –7999 to 32760
