Vibro-meter GSI127電耦合模塊 PDF資料
1.產 品 資 料 介 紹：
中文資料：
Vibro-meter GSI127 電耦合模塊是Vibro-meter公司設計的一款高性能電耦合器，廣泛應用于振動監測、狀態監測和故障診斷領域。此模塊的設計目標是提高傳感器信號的可靠性與準確性，并在工業環境中提供穩定的性能。以下是對該電耦合模塊的詳細介紹，包括其主要功能、技術規格和應用領域等。
主要功能
信號耦合：
- GSI127模塊用于將傳感器信號有效耦合到監測系統，確保信號的完整性和準確性。
頻率響應：
- 提供寬頻率響應，適合多種振動和聲學測量需求，以捕捉廣泛的信號頻率。
高輸入阻抗：
- 模塊設計具有高輸入阻抗，以降低傳感器信號的損失，確保信號傳輸?shù)母哔|(zhì)量。
過載保護：
- 內置過載和短路保護功能，保護模塊和連接的設備，確保系統的安全性和穩定性。
多種輸出選項：
- 提供多種輸出類型，以便與不同的監測系統和數據采集設備進行集成。
技術規格
輸入范圍：
- 適用于多種傳感器，包括壓電傳感器和其他類型的振動傳感器，確保多樣化的應用兼容性。
輸出信號：
- 輸出信號通常為標準的電壓或電流信號，具體輸出類型可根據應用需求選擇。
頻率響應范圍：
- 頻率響應范圍一般為0.1 Hz至100 kHz，確保捕獲到廣泛的振動頻率。
工作溫度范圍：
- 可在-40°C至+70°C的環境溫度下穩定工作，適合惡劣的工業環境。
電源要求：
- 通常支持24V DC供電，具有低功耗設計。
尺寸和安裝：
- 模塊化設計，適合標準安裝方式，方便集成到現有監測系統中。
英文資料：
The Vibro meter GSI127 electrical coupling module is a high-performance electrical coupler designed by Vibro meter company, widely used in the fields of vibration monitoring, condition monitoring, and fault diagnosis. The design goal of this module is to improve the reliability and accuracy of sensor signals and provide stable performance in industrial environments. The following is a detailed introduction to the electrical coupling module, including its main functions, technical specifications, and application areas.
major function
Signal coupling:
The GSI127 module is used to effectively couple sensor signals to the monitoring system, ensuring the integrity and accuracy of the signals.
Frequency response:
Provide broadband response, suitable for various vibration and acoustic measurement needs, to capture a wide range of signal frequencies.
High input impedance:
The module design features high input impedance to reduce sensor signal loss and ensure high-quality signal transmission.
Overload protection:
Built in overload and short circuit protection functions protect modules and connected devices, ensuring the safety and stability of the system.
Multiple output options:
Provide multiple output types for integration with different monitoring systems and data acquisition devices.
technical specifications
Input range:
Suitable for various sensors, including piezoelectric sensors and other types of vibration sensors, ensuring compatibility for diverse applications.
Output signal:
The output signal is usually a standard voltage or current signal, and the specific output type can be selected according to application requirements.
Frequency response range:
The frequency response range is generally from 0.1 Hz to 100 kHz, ensuring the capture of a wide range of vibration frequencies.
Working temperature range:
It can work stably in ambient temperatures ranging from -40 ° C to+70 ° C, suitable for harsh industrial environments.
Power requirements:
It usually supports 24V DC power supply and has a low-power design.
Size and installation:
Modular design, suitable for standard installation methods, easy to integrate into existing monitoring systems.
2.產 品 展 示
