Bently 3500/54 133396-01 位移監測器 PDF資料
1.產 品 資 料 介 紹：
中文資料：
Bently 3500/54 133396-01 位移監測器 是 GE Bently Nevada 公司生產的關鍵監測模塊，專為機器狀態監測和保護而設計。它屬于 3500 系列的監控系統，廣泛應用于大型旋轉機械設備的位移監測，包括汽輪機、壓縮機、發電機和泵等工業設備。
主要功能和特點：
實時位移監測：
- 該位移監測器專用于對旋轉機械的軸向或徑向位移進行監控。它通過高精度傳感器來檢測設備軸的位移情況，以防止由于位移超出規定范圍而造成的機械損壞或故障。
- 實時監測可以幫助預測設備潛在的失效，進行預防性維護。
高精度測量：
- 3500/54 采用先進的測量技術，能夠?qū)ξ灰七M(jìn)行高精度的監測。精確的位移數據可用于評估機器的運行狀態，并通過系統自動觸發報警或關機，避免事故發生。
- 特別適合需要高精度位移測量的應用場合，例如高轉速旋轉機械。
多通道設計：
- 該監測器支持多個輸入通道，可以同時監測多根軸的位移情況。這種多通道的設計提高了監測效率，適合用于復雜的機械設備中。
- 每個通道都可以獨立配置，適應不同設備的監測需求。
與 3500 系列系統集成：
- Bently 3500/54 模塊是 3500 系列在線監測和保護系統的一部分，能夠無縫集成到已有的 3500 系統中，與其他模塊協同工作，提供全面的設備狀態監控和保護。
- 該模塊可以與振動監測模塊、速度監測模塊等配合使用，為設備提供全方位的監控。
報警與保護功能：
- 該模塊可以設定報警限值，當位移超過設定值時，系統會自動觸發報警或啟動保護動作，例如減速或關閉設備。
- 監測器具備兩級報警（警告和危險）設置，能夠在不同位移水平下提供及時的反饋。
先進的數據處理和顯示：
- 監測器支持?jǐn)?shù)字處理，可以將采集到的數據進行分析處理，并通過顯示終端或遠程系統實時顯示設備位移狀態。
- 數據可以存儲并用于后續的故障分析與診斷，幫助優化設備運行和維護計劃。
可靠性和耐用性：
- Bently 3500 系列設計用于嚴苛的工業環境，能夠在高溫、振動和其他惡劣條件下保持可靠運行。模塊結構堅固，適用于長期在線監測。
英文資料：
The Bently 3500/54 133396-01 displacement monitor is a critical monitoring module produced by GE Bently Nevada, designed specifically for machine condition monitoring and protection. It belongs to the 3500 series monitoring system and is widely used for displacement monitoring of large rotating machinery equipment, including industrial equipment such as turbines, compressors, generators, and pumps.
Main functions and features:
Real time displacement monitoring:
This displacement monitor is specifically designed to monitor the axial or radial displacement of rotating machinery. It detects the displacement of the equipment axis through high-precision sensors to prevent mechanical damage or failure caused by displacement exceeding the specified range.
Real time monitoring can help predict potential equipment failures and perform preventive maintenance.
High precision measurement:
The 3500/54 adopts advanced measurement technology and is capable of high-precision monitoring of displacement. Accurate displacement data can be used to evaluate the operating status of machines and automatically trigger alarms or shutdowns through the system to avoid accidents.
Especially suitable for applications that require high-precision displacement measurement, such as high-speed rotating machinery.
Multi channel design:
This monitor supports multiple input channels and can simultaneously monitor the displacement of multiple axes. This multi-channel design improves monitoring efficiency and is suitable for use in complex mechanical equipment.
Each channel can be independently configured to meet the monitoring needs of different devices.
Integration with 3500 series systems:
The Bently 3500/54 module is part of the 3500 series online monitoring and protection system, which can be seamlessly integrated into existing 3500 systems and work in conjunction with other modules to provide comprehensive equipment status monitoring and protection.
This module can be used in conjunction with vibration monitoring module, speed monitoring module, etc. to provide comprehensive monitoring for the equipment.
Alarm and protection functions:
This module can set alarm limits. When the displacement exceeds the set value, the system will automatically trigger an alarm or initiate protective actions, such as slowing down or shutting down the equipment.
The monitor has a two-level alarm (warning and danger) setting, which can provide timely feedback at different displacement levels.
Advanced data processing and display:
The monitor supports digital processing and can analyze and process the collected data, and display the device displacement status in real-time through a display terminal or remote system.
Data can be stored and used for subsequent fault analysis and diagnosis, helping to optimize equipment operation and maintenance plans.
Reliability and Durability:
The Bently 3500 series is designed for harsh industrial environments and can maintain reliable operation under high temperatures, vibrations, and other harsh conditions. The module structure is sturdy and suitable for long-term online monitoring.
2.產 品 展 示
