IC695ALG508-AA 電阻溫度檢測器 PDF資料
1.產 品 資 料 介 紹：
中文資料：
GE Fanuc IC695ALG508-AA 是 PACSystems RX3i 系列的模擬輸入模塊，專門用于支持電阻溫度檢測器（RTD）信號的輸入。該模塊可直接連接 RTD 傳感器，適用于工業自動化和過程控制系統中的高精度溫度測量。
主要特點：
通道數量：
- 提供 8 路模擬輸入通道，支持多個 RTD 傳感器的同時連接。
支持的傳感器類型：
- RTD 傳感器：模塊支持各種類型的 RTD 傳感器，包括常見的 PT100、PT1000 等不同精度等級和不同溫度范圍的電阻溫度檢測器。
溫度測量范圍：
- 具體測量范圍取決于所使用的 RTD 傳感器類型，一般支持從 -200°C 到 +850°C 的溫度范圍，適合多種工業應用。
精度和分辨率：
- 具有高精度和高分辨率，通常為 16 位分辨率，確保溫度測量的精確性。
線性化和補償：
- 模塊內置線性化功能，能夠自動將 RTD 信號轉換為實際的溫度值。
- 同時支持導線補償功能，可以消除由于 RTD 導線電阻造成的測量誤差，確保測量的準確性。
診斷功能：
- 具備自診斷能力，支持傳感器開路檢測和系統故障檢測，有助于及時發現和解決問題。
電氣隔離：
- 提供通道與系統之間的電氣隔離，增強抗干擾能力，提高系統可靠性。
配置靈活性：
- 通過 GE Fanuc 的編程工具進行參數配置，可以靈活選擇 RTD 類型、輸入范圍以及采樣速率等參數，滿足不同應用需求。
技術規格：
- 型號：IC695ALG508-AA
- 輸入通道：8 路 RTD 模擬輸入
- 支持的 RTD 類型：PT100、PT1000、其他標準 RTD
- 測量范圍：-200°C 至 +850°C（取決于 RTD 類型）
- 分辨率：16 位
- 電氣隔離：提供系統與輸入的隔離
- 安裝方式：安裝在 RX3i 機架中，支持 DIN 導軌或機架安裝
- 接口：使用標準的接線端子與外部 RTD 傳感器連接
英文資料：
GE Fanuc IC695ALG508-AA is an analog input module of PACSystems RX3i series, specifically designed to support the input of resistance temperature detector (RTD) signals. This module can be directly connected to RTD sensors and is suitable for high-precision temperature measurement in industrial automation and process control systems.
Main features:
Number of channels:
Provide 8 analog input channels and support simultaneous connection of multiple RTD sensors.
Supported sensor types:
RTD Sensor: The module supports various types of RTD sensors, including common PT100, PT1000 and other resistance temperature detectors with different accuracy levels and temperature ranges.
Temperature measurement range:
The specific measurement range depends on the type of RTD sensor used, and generally supports a temperature range from -200 ° C to+850 ° C, suitable for various industrial applications.
Accuracy and Resolution:
It has high precision and resolution, usually 16 bit resolution, to ensure the accuracy of temperature measurement.
Linearization and compensation:
The module has built-in linearization function, which can automatically convert RTD signals into actual temperature values.
Simultaneously supporting wire compensation function, it can eliminate measurement errors caused by RTD wire resistance and ensure measurement accuracy.
Diagnostic function:
Having self diagnostic capabilities, supporting sensor open circuit detection and system fault detection, helps to detect and solve problems in a timely manner.
Electrical isolation:
Provide electrical isolation between channels and systems, enhance anti-interference capabilities, and improve system reliability.
Configuration flexibility:
By using GE Fanuc's programming tool for parameter configuration, it is possible to flexibly select parameters such as RTD type, input range, and sampling rate to meet different application requirements.
Technical specifications:
Model: IC695ALG508-AA
Input channel: 8-channel RTD analog input
Supported RTD types: PT100, PT1000, other standard RTDs
Measurement range: -200 ° C to+850 ° C (depending on RTD type)
Resolution: 16 bits
Electrical isolation: providing isolation between the system and input
Installation method: Installed in the RX3i rack, supporting DIN rail or rack installation
Interface: Connect to external RTD sensors using standard wiring terminals
