Brooks BM70020/CPU85 XYZ控制板 PDF資料
1.產 品 資 料 介 紹：
中文資料：
Brooks BM70020/CPU85 XYZ 控制板是一款專門設計用于高精度控制和多軸運動控制的工業控制板。此控制板在自動化系統和機器人控制中有廣泛應用，尤其適用于需要精確定位和復雜運動管理的場景，如半導體制造、精密加工和實驗室自動化。
主要特點
- 多軸運動控制：支持 XYZ 軸等多軸控制，適合需要精確定位的設備，提供穩定的同步控制。
- 高性能處理器：配備 CPU85 處理器，確保實時數據處理和響應，適合復雜控制任務和高速操作。
- 模塊化設計：控制板結構緊湊，易于集成至多種自動化設備或生產線中，方便進行系統擴展和升級。
- 多種接口支持：具備豐富的通信接口，如 RS-232、CAN、Ethernet 等，以實現與傳感器、執行器和其他設備的無縫連接。
- 高精度反饋系統：內置反饋機制，能夠精確監控和調整設備位置，確保設備的控制精度和響應速度。
- 堅固耐用：設計符合工業標準，具備較強的抗干擾能力和耐高溫、耐振動性能，適合長時間在工業環境下運行。
應用領域
- 半導體制造：在晶圓處理、曝光和封裝設備中使用，實現高精度的設備控制和定位。
- 精密加工：適合數控機床、激光切割和焊接等需要多軸控制的設備，確保加工精度和效率。
- 機器人控制：可用作機器人的核心控制單元，支持多關節協調和復雜路徑規劃。
- 實驗室自動化：用于高精度的樣品傳輸和操作設備中，確保實驗操作的準確性和重復性。
技術規格概述
- 處理器：CPU85 高性能處理器，支持多任務處理。
- 電源要求：通常為 24V DC，需根據具體型號確認。
- 接口類型：包括 RS-232、CAN 和 Ethernet 等工業接口。
- 工作溫度：適用于 0°C 至 50°C 的工業環境。
- 尺寸：緊湊模塊化設計，便于嵌入和安裝。
英文資料：
The Brooks BM70020/CPU85 XYZ control board is an industrial control board specifically designed for high-precision control and multi axis motion control. This control board is widely used in automation systems and robot control, especially in scenarios that require precise positioning and complex motion management, such as semiconductor manufacturing, precision machining, and laboratory automation.
main features
Multi axis motion control: Supports multi axis control such as XYZ axes, suitable for equipment that requires precise positioning, and provides stable synchronous control.
High performance processor: equipped with CPU85 processor, ensuring real-time data processing and response, suitable for complex control tasks and high-speed operations.
Modular design: The control board has a compact structure and is easy to integrate into various automation equipment or production lines, making it convenient for system expansion and upgrades.
Multiple interface support: Equipped with rich communication interfaces such as RS-232, CAN, Ethernet, etc., to achieve seamless connection with sensors, actuators, and other devices.
High precision feedback system: Built in feedback mechanism that can accurately monitor and adjust device position, ensuring control accuracy and response speed of the device.
Durable and sturdy: Designed to meet industrial standards, it has strong anti-interference ability, high temperature resistance, and vibration resistance, making it suitable for long-term operation in industrial environments.
application area
Semiconductor manufacturing: used in wafer processing, exposure, and packaging equipment to achieve high-precision equipment control and positioning.
Precision machining: suitable for equipment that requires multi axis control such as CNC machine tools, laser cutting, and welding, ensuring machining accuracy and efficiency.
Robot control: can be used as the core control unit of robots, supporting multi joint coordination and complex path planning.
Laboratory automation: used in high-precision sample transfer and operation equipment to ensure the accuracy and repeatability of experimental operations.
Overview of Technical Specifications
Processor: CPU85 high-performance processor, supporting multitasking.
Power requirements: Typically 24V DC, to be confirmed based on the specific model.
Interface types: including industrial interfaces such as RS-232, CAN, and Ethernet.
Working temperature: Suitable for industrial environments ranging from 0 ° C to 50 ° C.
Size: Compact modular design, easy to embed and install.
2.產 品 展 示
