AADVANCE T9110 處理器模塊 PDF資料
1.產 品 資 料 介 紹：
中文資料：
AADVANCE T9110 處理器模塊 是由霍尼韋爾（Honeywell）開發的一款用于 AADVANCE 安全控制系統 的關鍵組件。該模塊為系統提供了高性能的處理能力，用于工業安全和控制應用，尤其適用于復雜的分布式控制系統 (DCS) 和緊急停機系統 (ESD)。
產品概述
- 型號：T9110
- 產品類型：處理器模塊
- 品牌：Honeywell AADVANCE 系列
- 主要功能：實現邏輯運算、任務管理和數據通信，為 AADVANCE 系統提供核心計算能力。
主要特點
模塊化設計：
- 支持冗余配置，確保系統在硬件故障時能夠繼續運行。
- 易于與其他 AADVANCE 模塊集成，例如 I/O 模塊和通信模塊。
高性能處理能力：
- 運行復雜的邏輯程序，支持快速的輸入/輸出處理和系統響應。
- 內部任務調度能力強，適用于大規模和高要求的控制系統。
可靠性與安全性：
- 符合工業安全標準 (如 IEC 61508)，可應用于 SIL 2/3 的安全場景。
- 支持熱插拔操作，方便系統維護和升級。
通信支持：
- 與其他模塊通過專用總線進行高效通信。
- 兼容常見的工業協議，支持與上位系統和第三方設備的數據交互。
診斷功能：
- 內置診斷工具，可實時監控模塊狀態，及時發現故障。
- 支持在線調試和系統故障日志記錄。
應用場景
過程控制：
- 用于石油、天然氣、化工等行業的工藝過程控制。
- 確保生產安全和優化。
緊急停機系統 (ESD)：
- 在緊急情況下迅速響應，確保人員和設備的安全。
- 與火氣報警系統 (FGS) 集成，提供全面的安全保障。
分布式控制系統 (DCS)：
- 適用于大規模分布式控制場景，提高系統的可靠性和靈活性。
關鍵安全應用：
- 如煉油廠、發電廠和核電站的安全監控和控制。
技術規格
- 電源要求：通常從系統的冗余電源供電。
- 環境適應性：
- 工作溫度范圍：適用于工業環境。
- 抗電磁干擾能力強，符合工業環境標準。
- 尺寸和重量：
- 緊湊型設計，適用于標準控制柜安裝。
優勢
- 高可用性：模塊支持冗余配置，顯著提高系統可靠性。
- 擴展性強：可與多個 I/O 和通信模塊組合，滿足不同規模的需求。
- 易維護：支持在線更換和快速診斷，減少停機時間。
英文資料：
The AADVANCE T9110 processor module is a critical component developed by Honeywell for use in AADVANCE safety control systems. This module provides high-performance processing capabilities for industrial safety and control applications, particularly suitable for complex distributed control systems (DCS) and emergency shutdown systems (ESD).
Product Overview
Model: T9110
Product Type: Processor Module
Brand: Honeywell AADVANCE series
Main functions: Implement logical operations, task management, and data communication, providing core computing capabilities for the AADVANCE system.
main features
Modular design:
Support redundant configuration to ensure that the system can continue to operate in the event of hardware failure.
Easy to integrate with other AADVANCE modules, such as I/O modules and communication modules.
High performance processing capability:
Run complex logic programs that support fast input/output processing and system response.
Strong internal task scheduling capability, suitable for large-scale and high demand control systems.
Reliability and safety:
Compliant with industrial safety standards such as IEC 61508, it can be applied to safety scenarios up to SIL 2/3.
Support hot plug operation, convenient for system maintenance and upgrade.
Communication support:
Efficiently communicate with other modules through a dedicated bus.
Compatible with common industrial protocols, supporting data exchange with upper level systems and third-party devices.
Diagnostic function:
Built in diagnostic tools can monitor module status in real-time and detect faults in a timely manner.
Support online debugging and system fault logging.
Application scenarios
Process control:
Used for process control in industries such as petroleum, natural gas, and chemical.
Ensure production safety and optimization.
Emergency Shutdown System (ESD):
Quickly respond in emergency situations to ensure the safety of personnel and equipment.
Integrate with the Fire and Gas Alarm System (FGS) to provide comprehensive safety assurance.
Distributed Control System (DCS):
Suitable for large-scale distributed control scenarios, improving system reliability and flexibility.
Critical security applications:
Safety monitoring and control of oil refineries, power plants, and nuclear power plants.
technical specifications
Power requirements: Usually powered by the redundant power supply of the system.
Environmental adaptability:
Working temperature range: suitable for industrial environments.
Strong anti-interference ability, in line with industrial environmental standards.
Size and weight:
Compact design, suitable for standard control cabinet installation.
advantage
High availability: The module supports redundant configuration, significantly improving system reliability.
Strong scalability: can be combined with multiple I/O and communication modules to meet the needs of different scales.
Easy to maintain: supports online replacement and quick diagnosis, reducing downtime.
2.產 品 展 示
