ABB YPO104數字輸出板 PDF資料
1.產 品 資 料 介 紹：
中文資料：
ABB YPO104 數字輸出板是工業自動化和控制系統中的關鍵模塊，用于向外部設備發送數字信號。它通過將控制器的指令轉換為數字輸出信號，驅動現場設備如電磁閥、繼電器和指示燈。以下是有關該模塊的詳細信息：
主要功能和特點
多通道數字輸出
- 提供多個獨立數字輸出通道，支持同時控制多個外部設備。
- 每個通道可獨立操作，靈活性高。
信號驅動能力
- 支持多種輸出電壓等級（如24V DC）。
- 可驅動繼電器、電磁閥和其他數字輸入設備。
高可靠性設計
- 輸出通道具備過載保護功能，有效避免設備損壞。
- 配備狀態指示燈，顯示每個通道的工作狀態。
隔離保護
- 通道間和對地電氣隔離，增強系統抗干擾能力。
- 確保在惡劣工業環境下的穩定運行。
診斷功能
- 支持通道級故障檢測，如短路和過流報警。
- 提供實時監控，提高維護效率。
技術規格
| 參數 | 詳情 |
|---|---|
| 輸出通道數量 | 16 通道或更高 |
| 輸出電壓范圍 | 24V DC（典型值） |
| 輸出電流 | 每通道最大500 mA（視具體型號而定） |
| 隔離電壓 | 通道與通道/地之間 500V |
| 響應時間 | < 5 毫秒 |
| 工作溫度范圍 | -20°C 至 +70°C |
| 安裝方式 | DIN 導軌或機架式安裝 |
| 尺寸 | 標準模塊尺寸 |
應用領域
工業自動化
- 用于控制生產線上的執行器、報警器、和其他數字設備。
過程控制
- 驅動控制系統中的開關設備，適用于石油化工、發電廠等場景。
樓宇自動化
- 控制照明、門禁和安防設備。
智能制造
- 集成在生產線的控制系統中，實現高精度數字信號輸出。
英文資料：
The ABB YPO104 digital output board is a critical module in industrial automation and control systems, used to send digital signals to external devices. It drives field devices such as solenoid valves, relays, and indicator lights by converting controller instructions into digital output signals. The following is detailed information about the module:
Main functions and features
Multi channel digital output
Provide multiple independent digital output channels and support simultaneous control of multiple external devices.
Each channel can be operated independently, with high flexibility.
Signal driven capability
Supports multiple output voltage levels (such as 24V DC).
Can drive relays, solenoid valves, and other digital input devices.
High reliability design
The output channel has overload protection function, effectively avoiding equipment damage.
Equipped with status indicator lights to display the working status of each channel.
Isolation protection
Channel to channel and ground electrical isolation enhance the system's anti-interference ability.
Ensure stable operation in harsh industrial environments.
Diagnostic function
Support channel level fault detection, such as short circuit and overcurrent alarms.
Provide real-time monitoring to improve maintenance efficiency.
technical specifications
Parameter details
Number of output channels: 16 channels or higher
Output voltage range 24V DC (typical value)
The maximum output current per channel is 500 mA (depending on the specific model)
Isolation voltage channel and channel/ground 500V
Response time<5 milliseconds
Working temperature range -20 ° C to+70 ° C
Installation method: DIN rail or rack mounted installation
Size standard module size
application area
industrial automation
Used to control actuators, alarms, and other digital devices on the production line.
process control
The switch equipment in the drive control system is suitable for scenarios such as petrochemicals and power plants.
Building automation
Control lighting, access control, and security equipment.
Intelligent Manufacturing
Integrated into the control system of the production line to achieve high-precision digital signal output.
