Marine Mas PD-5010-LCD接口模塊 PDF資料
1.產 品 資 料 介 紹：
中文資料：
Marine Mas PD-5010-LCD 接口模塊是一種專為船舶和海洋應用設計的控制和監控設備。它通過 LCD 顯示界面和接口功能，實現系統運行參數的直觀顯示和操作，通常用于連接船舶的各類控制設備、傳感器和數據采集系統。以下是該模塊的詳細信息：
主要功能和特點
LCD 顯示界面
- 配備高亮度 LCD 顯示屏，提供實時操作數據和狀態信息。
- 支持多行顯示，清晰易讀，可顯示報警和設備參數。
接口支持
- 支持多種通信協議，用于連接船舶的控制系統和外部設備。
- 提供標準化數據接口，如 RS-232、RS-485、CAN 總線或以太網。
多功能集成
- 用于監控多個輸入信號并實時處理數據。
- 提供多通道輸入和輸出，用于傳感器、執行器和控制設備的連接。
用戶友好設計
- 帶有按鍵或觸摸屏設計，方便用戶設置和調節參數。
- 配備直觀菜單導航，支持快速操作和配置。
堅固可靠
- 采用工業級設計，具備防振、防水和防腐蝕特性，適應惡劣的海洋環境。
- 工作溫度范圍廣，滿足船舶運行條件下的可靠性要求。
報警功能
- 內置報警系統，顯示超限、故障和系統狀態信息。
- 可通過接口發送報警信號至中央控制系統。
技術規格
| 參數 | 詳情 |
|---|---|
| 顯示類型 | LCD 顯示屏，支持多行文本和圖形界面 |
| 通信接口 | RS-232、RS-485、CAN 總線、以太網等 |
| 輸入信號類型 | 模擬信號（電流/電壓）、數字信號 |
| 輸出信號類型 | 數字輸出、繼電器觸點 |
| 工作電源 | 24V DC 或 230V AC |
| 工作溫度范圍 | -20°C 至 +70°C |
| 安裝方式 | 面板安裝或機架安裝 |
| 外殼防護等級 | IP65 或更高 |
應用領域
船舶自動化
- 用于船舶發動機、推進系統的狀態監控和控制。
- 集成于船舶綜合監控系統，管理多設備運行參數。
海洋平臺
- 用于采集和顯示海洋平臺關鍵設備的運行數據。
數據采集和控制
- 作為傳感器接口模塊，采集和處理環境數據，如溫度、壓力和液位。
報警和狀態管理
- 提供船舶和海洋系統的報警信息，提升運行安全性。
英文資料：
The Marine Mas PD-5010-LCD interface module is a control and monitoring device designed specifically for ship and marine applications. It achieves intuitive display and operation of system operating parameters through LCD display interface and interface functions, and is usually used to connect various control devices, sensors, and data acquisition systems of ships. The following is the detailed information of the module:
Main functions and features
LCD display interface
Equipped with a high brightness LCD display screen, providing real-time operational data and status information.
Support multi line display, clear and easy to read, can display alarms and device parameters.
Interface support
Supports multiple communication protocols for connecting ship control systems and external devices.
Provide standardized data interfaces such as RS-232, RS-485, CAN bus, or Ethernet.
Multi functional integration
Used to monitor multiple input signals and process data in real-time.
Provide multi-channel input and output for connecting sensors, actuators, and control devices.
User friendly design
Equipped with buttons or touch screen design, it is convenient for users to set and adjust parameters.
Equipped with intuitive menu navigation, supporting quick operation and configuration.
Durable and reliable
Adopting industrial grade design, it has anti vibration, waterproof and anti-corrosion characteristics, and is suitable for harsh marine environments.
The working temperature range is wide, meeting the reliability requirements under ship operating conditions.
Alarm function
Built in alarm system, displaying information on exceeding limits, faults, and system status.
Alarm signals can be sent to the central control system through the interface.
technical specifications
Parameter details
Display type: LCD display screen, supporting multiple lines of text and graphical interface
Communication interfaces RS-232, RS-485, CAN bus, Ethernet, etc
Input signal type: analog signal (current/voltage), digital signal
Output signal type: digital output, relay contact
Working power supply 24V DC or 230V AC
Working temperature range -20 ° C to+70 ° C
Installation method: panel installation or rack installation
Shell protection level IP65 or higher
application area
Ship automation
Used for status monitoring and control of ship engines and propulsion systems.
Integrated into the ship's comprehensive monitoring system, managing the operating parameters of multiple devices.
Ocean platform
Used to collect and display operational data of key equipment on offshore platforms.
Data collection and control
As a sensor interface module, it collects and processes environmental data such as temperature, pressure, and liquid level.
Alarm and status management
Provide alarm information for ships and marine systems to enhance operational safety.
2.產 品 展 示
