VIBRO-METER VM600 MPC4 200-510-064-034 200-610-100-034機械保護卡 PDF資料
1.產 品 資 料 介 紹：
中文資料：
VIBRO-METER VM600 MPC4機械保護卡（型號：200-510-064-034 / 200-610-100-034）是 Vibro-Meter（現為 Meggitt 公司）旗下 VM600 系統的重要組件，專為旋轉機械和關鍵設備提供高精度的振動和狀態監測。此卡件適用于對工業設備運行狀況進行實時監測和保護，廣泛用于航空、發電、石油天然氣、化工等高要求領域。
產品概述
品牌與型號：
- 品牌： Vibro-Meter / Meggitt
- 型號： MPC4（200-510-064-034）和 IOC4T（200-610-100-034）
設備類型：
- 機械保護卡（振動監測和保護模塊）
適配系統：
- VM600 系列機械監測和保護系統
主要功能
振動與狀態監測：
- 實時監測機械振動、軸位移、轉速等參數，預防設備故障。
機械保護功能：
- 當檢測到異常狀態（如振動超限）時，觸發報警或保護動作（如緊急停機）。
多通道支持：
- 支持多通道數據采集，可同時監測多個點位，提升監測覆蓋率。
高精度與實時性：
- 提供高分辨率測量與實時響應，確保關鍵設備安全。
數據通信與集成：
- 支持與上位機、DCS/PLC 系統的通信，便于集中管理和分析。
技術規格
| 參數 | 詳細信息 |
|---|---|
| 輸入類型 | 振動信號、軸位移、速度傳感器、轉速傳感器等 |
| 通道數量 | 支持多通道輸入（通常為 4-8 通道） |
| 信號輸出 | 模擬信號 (4-20 mA)、繼電器報警、數字信號 (MODBUS, TCP/IP 等) |
| 測量精度 | 高精度，適用于微小振動監測 |
| 響應時間 | 實時響應，毫秒級 |
| 通信接口 | 標準工業接口（支持 MODBUS 或以太網） |
| 電源需求 | 24V DC 或系統提供 |
| 工作溫度范圍 | -25°C 至 +70°C |
| 防護等級 | 工業標準，滿足惡劣環境要求 |
英文資料：
The VIBRO-METER VM600 MPC4 mechanical protection card (model: 200-510-064-034/200-610-100-034) is an important component of the VM600 system under Vibro Meter (now Meggitt), designed to provide high-precision vibration and status monitoring for rotating machinery and critical equipment. This card is suitable for real-time monitoring and protection of the operation status of industrial equipment, and is widely used in high demand fields such as aviation, power generation, oil and gas, and chemical industry.
Product Overview
Brand and Model:
Brand: Vibro Meter/Meggitt
Model: MPC4 (200-510-064-034) and IOC4T (200-610-100-034)
Equipment type:
Mechanical protection card (vibration monitoring and protection module)
Adaptation system:
VM600 series mechanical monitoring and protection system
major function
Vibration and condition monitoring:
Real time monitoring of mechanical vibration, shaft displacement, speed and other parameters to prevent equipment failures.
Mechanical protection function:
When an abnormal state is detected (such as vibration exceeding the limit), an alarm or protective action (such as emergency stop) is triggered.
Multi channel support:
Support multi-channel data collection, can simultaneously monitor multiple points, and improve monitoring coverage.
High precision and real-time performance:
Provide high-resolution measurement and real-time response to ensure the safety of critical equipment.
Data Communication and Integration:
Support communication with the upper computer and DCS/PLC system for centralized management and analysis.
technical specifications
Detailed parameter information
Input type: vibration signal, shaft displacement, speed sensor, speed sensor, etc
The number of channels supports multi-channel input (usually 4-8 channels)
Signal output analog signal (4-20 mA), relay alarm, digital signal (MODBUS, TCP/IP, etc.)
High measurement accuracy, suitable for monitoring small vibrations
Real time response time, millisecond level
Communication interface standard industrial interface (supporting MODBUS or Ethernet)
Power requirement 24V DC or provided by the system
Working temperature range -25 ° C to+70 ° C
Industrial standard for protection level, meeting the requirements of harsh environments
2.產 品 展 示
