HONEYWELL 51403422-150通信控制器 PDF資料
1.產 品 資 料 介 紹：
中文資料：
Honeywell 51403422-150 通信控制器是用于工業自動化和控制系統的關鍵模塊，專注于管理和優化系統內外的通信流程。該模塊在復雜分布式控制系統（DCS）中起到核心作用，確保數據交換的高效性和可靠性。
產品概述
品牌：
- Honeywell (霍尼韋爾)
型號：
- 51403422-150
類型：
- 通信控制器模塊 (Communication Controller Module)
功能：
- 管理多種通信協議
- 支持主控制器與其他子模塊之間的數據交換
- 提供實時數據處理和傳輸能力
產品特點
多協議支持：
- 支持多種工業標準通信協議，如 Modbus、Ethernet、TCP/IP 等，適應廣泛應用需求。
高性能數據處理：
- 提供高速處理能力，保證實時通信和控制的流暢性。
模塊化設計：
- 緊湊的插拔式設計，便于系統集成與維護。
內置診斷功能：
- 自動監控模塊狀態，提供故障診斷和報警功能，簡化故障排除。
可靠性高：
- 設計符合工業級標準，適合在惡劣環境中長期運行。
兼容性強：
- 與 Honeywell 的 Experion PKS 系統無縫集成，同時兼容其他 Honeywell 控制模塊。
技術規格
| 參數 | 詳細信息 |
|---|---|
| 通信協議支持 | Modbus, Ethernet, TCP/IP, Honeywell 專有協議 |
| 處理能力 | 高速多任務數據處理 |
| 工作電壓 | 24V DC 或根據配置要求 |
| 功耗 | 低功耗設計 |
| 工作溫度范圍 | -20°C 至 +60°C |
| 存儲溫度范圍 | -40°C 至 +85°C |
| 濕度范圍 | 5% 至 95%（無冷凝） |
| 安裝方式 | DIN 導軌或機架安裝 |
| 連接接口 | 標準 RJ45 網絡端口和其他工業 I/O 接口 |
| 診斷功能 | 內置自檢和錯誤日志記錄 |
英文資料：
The Honeywell 51403422-150 communication controller is a key module used in industrial automation and control systems, focusing on managing and optimizing communication processes inside and outside the system. This module plays a core role in complex distributed control systems (DCS), ensuring the efficiency and reliability of data exchange.
Product Overview
Brand:
Honeywell
model:
51403422-150
Type:
Communication Controller Module
Function:
Manage multiple communication protocols
Support data exchange between the main controller and other submodules
Provide real-time data processing and transmission capabilities
Product Features
Multi protocol support:
Supports multiple industrial standard communication protocols, such as Modbus, Ethernet, TCP/IP, etc., to meet a wide range of application needs.
High performance data processing:
Provide high-speed processing capability to ensure smooth real-time communication and control.
Modular design:
Compact plug-in design, convenient for system integration and maintenance.
Built in diagnostic function:
Automatically monitor module status, provide fault diagnosis and alarm functions, simplify troubleshooting.
High reliability:
Designed to meet industrial standards and suitable for long-term operation in harsh environments.
Strong compatibility:
Seamless integration with Honeywell's Expert PKS system and compatibility with other Honeywell control modules.
technical specifications
Detailed parameter information
The communication protocol supports Modbus, Ethernet, TCP/IP, and Honeywell proprietary protocols
High speed multitasking data processing capability
Working voltage 24V DC or according to configuration requirements
Low power consumption design
Working temperature range -20 ° C to+60 ° C
Storage temperature range -40 ° C to+85 ° C
Humidity range 5% to 95% (non condensing)
Installation method: DIN rail or rack installation
Connection interface standard RJ45 network port and other industrial I/O interfaces
Diagnostic function with built-in self-test and error logging
2.產 品 展 示
