A30-30-10RT接觸器 PDF資料
1.產 品 資 料 介 紹：
中文資料：
A30-30-10RT 接觸器 是一款由 Schneider Electric（施耐德電氣） 生產的工業控制和電氣保護元件，廣泛應用于電氣控制系統中。接觸器主要用于控制高電流設備的開關，如電動機、加熱設備、照明系統等。A30-30-10RT 是其型號之一，具有特定的電氣參數和應用特性。
主要特點：
標準設計與高性能：
- A30-30-10RT 接觸器采用標準化設計，適用于各種電氣控制應用，能夠提供可靠的開關控制。
- 它具有較強的耐用性，適合長期高頻使用，特別是在工業環境中。
接觸器電流與額定負載：
- 該接觸器的額定電流通常為 30A，適合用于控制電流為 30A 以下的負載。它的額定電壓通常為 380V-415V AC，也適用于其他標準電壓范圍。
輔助觸點：
- A30-30-10RT 通常配有輔助觸點，支持多路信號控制與反饋。通過附加觸點模塊，可以擴展接觸器的控制能力。
適用環境：
- 接觸器的設計考慮了工業環境的嚴苛性，能夠在-25°C到+40°C 的溫度范圍內穩定工作。它通常具備防塵、防水等功能，適用于常見的工業應用環境。
高可靠性與長使用壽命：
- A30-30-10RT 具有高開關頻率與較長的機械壽命，適合用于自動化系統和頻繁啟停的設備。它的壽命通?？梢赃_(dá)到 1百萬次 以上的操作周期。
過載與短路保護：
- 接觸器本身通常具有過載保護功能，避免電機和其他負載因超載或電流異常而損壞。
- 可以與熱繼電器配合使用，提供額外的過載保護功能。
輔助功能：
- 它可以配備額外的附件，例如線圈降壓設備、延時開關等，以滿足具體的控制要求。
型號與標識：
- A30-30-10RT 的 “A30” 代表接觸器的系列或類型，“30” 表示其額定電流為 30A，“10” 表示具有 10 個輔助觸點（根據不同配置可能有所變化），而 “RT” 通常指的是接觸器類型或特定功能。
技術規格：
- 額定電流：30A
- 額定電壓：380V - 415V AC（可能支持其他電壓配置）
- 額定操作電流：約30A（視具體應用和負載而定）
- 操作方式：電磁式開關控制
- 額定功率：一般用于電動機、照明和其他負載的控制
- 機械壽命：1百萬次操作
- 溫度范圍：-25°C 到 +40°C
- 防護等級：通常為 IP20，但可以根據具體配置提供更高防護等級。
- 安裝方式：可適應多種安裝方式，適用于標準配電盤和控制柜。
英文資料：
A30-30-10RT contactor is an industrial control and electrical protection component produced by Schneider Electric, widely used in electrical control systems. Contactors are mainly used to control the switching of high current equipment, such as motors, heating equipment, lighting systems, etc. A30-30-10RT is one of its models, with specific electrical parameters and application characteristics.
Main features:
Standard design and high performance:
The A30-30-10RT contactor adopts standardized design and is suitable for various electrical control applications, providing reliable switch control.
It has strong durability and is suitable for long-term high-frequency use, especially in industrial environments.
Contactor current and rated load:
The rated current of this contactor is usually 30A, suitable for controlling loads with currents below 30A. Its rated voltage is usually 380V-415V AC and is also suitable for other standard voltage ranges.
Auxiliary contact:
A30-30-10RT is usually equipped with auxiliary contacts, supporting multi-channel signal control and feedback. By adding contact modules, the control capability of the contactor can be expanded.
Applicable environment:
The design of the contactor takes into account the harsh industrial environment and can operate stably within a temperature range of -25 ° C to+40 ° C. It usually has functions such as dust and water resistance, and is suitable for common industrial application environments.
High reliability and long service life:
A30-30-10RT has high switching frequency and long mechanical life, making it suitable for use in automation systems and equipment with frequent start stop. Its lifespan can typically reach over 1 million operating cycles.
Overload and short circuit protection:
The contactor itself usually has overload protection function to prevent damage to the motor and other loads due to overload or abnormal current.
Can be used in conjunction with a thermal relay to provide additional overload protection function.
Auxiliary functions:
It can be equipped with additional accessories such as coil voltage reduction devices, delay switches, etc. to meet specific control requirements.
Model and identification:
The "A30" of A30-30-10RT represents the series or type of contactor, "30" indicates its rated current of 30A, "10" indicates it has 10 auxiliary contacts (which may vary depending on different configurations), and "RT" usually refers to the type or specific function of the contactor.
Technical specifications:
Rated current: 30A
Rated voltage: 380V -415V AC (may support other voltage configurations)
Rated operating current: approximately 30A (depending on specific application and load)
Operation mode: Electromagnetic switch control
Rated power: generally used for controlling electric motors, lighting, and other loads
Mechanical lifespan: 1 million operations
Temperature range: -25 ° C to+40 ° C
Protection level: Typically IP20, but higher protection levels can be provided depending on specific configurations.
Installation method: It can adapt to various installation methods and is suitable for standard distribution panels and control cabinets.
2.產 品 展 示
