TRICONEX 8310 電源模塊 PDF資料
1.產 品 資 料 介 紹：
中文資料：
TRICONEX 8310 電源模塊 是一款專為 Triconex 系統設計的電源模塊，屬于 Tricon 可信安全控制系統的一部分。Triconex 系統廣泛應用于安全關鍵的工業自動化環境，如石油天然氣、化工、電力等行業。該電源模塊用于為 Triconex 控制系統中的其他模塊提供穩定、可靠的電源支持，確保系統在關鍵時刻的高效運行。
主要特性：
高可靠性：
- 作為 Triconex 系統的一部分，8310 電源模塊設計符合高安全性和高可靠性標準，確保在嚴苛環境下長期穩定運行。
- 模塊通常具有冗余設計，支持系統電源的故障檢測和切換功能，最大限度減少停機時間。
寬輸入電壓范圍：
- 8310 電源模塊支持廣泛的輸入電壓范圍，通常為 120V 或 240V AC 輸入，適應不同地區和環境的電力供應條件。
- 提供恒定的輸出電壓，以供系統中的其他模塊（如 CPU、I/O 模塊、通訊模塊等）穩定工作。
高效能與節能：
- 8310 電源模塊具有較高的能效比，通過優化電源轉換過程，降低系統運行中的能量損耗，提升整體系統的能源利用效率。
- 模塊設計緊湊，節省空間，并能有效降低設備散熱，適應更高密度的安裝要求。
電源冗余支持：
- 支持冗余電源配置，可以配置多個電源模塊同時工作，一旦其中一個電源模塊出現故障，系統可以自動切換到備用電源，保障系統的連續穩定運行。
- 電源模塊可與其他關鍵模塊一起組成一個高度可靠的系統架構，在關鍵時刻提供不間斷電源支持。
診斷和監控功能：
- 8310 電源模塊配備了診斷功能，能夠?qū)崟r(shí)監控電源狀態和系統運行狀態。一旦出現電源故障或電壓異常，模塊會通過系統的診斷功能及時報告，方便維護人員進行故障排查。
- 支持在線監測和遠程訪問，便于運維人員在不中斷生產的情況下進行系統維護和故障處理。
緊湊和模塊化設計：
- 模塊化設計使得安裝和維護更加方便，用戶可以根據需要輕松添加或更換電源模塊。
- 緊湊型設計幫助節省機架空間，適用于需要高密度安裝的場合。
英文資料：
The TriconeX 8310 power module is a power module designed specifically for the Triconex system and is part of the Tricon Trusted Safety Control System. The Triconex system is widely used in safety critical industrial automation environments, such as the oil and gas, chemical, and power industries. This power module is used to provide stable and reliable power support for other modules in the Triconex control system, ensuring efficient operation of the system during critical moments.
Main features:
High reliability:
As part of the Triconex system, the 8310 power module is designed to meet high safety and reliability standards, ensuring long-term stable operation in harsh environments.
Modules typically have redundant designs that support fault detection and switching of system power, minimizing downtime to the greatest extent possible.
Wide input voltage range:
The 8310 power module supports a wide range of input voltages, typically 120V or 240V AC input, to adapt to power supply conditions in different regions and environments.
Provide a constant output voltage to ensure stable operation of other modules in the system, such as CPU, I/O modules, communication modules, etc.
High efficiency and energy conservation:
The 8310 power module has a high energy efficiency ratio. By optimizing the power conversion process, it reduces energy loss during system operation and improves the overall energy utilization efficiency of the system.
The module design is compact, saves space, and can effectively reduce device heat dissipation, adapting to higher density installation requirements.
Power redundancy support:
Supporting redundant power configuration, multiple power modules can be configured to work simultaneously. Once one of the power modules fails, the system can automatically switch to the backup power supply to ensure the continuous and stable operation of the system.
The power module can be combined with other critical modules to form a highly reliable system architecture, providing uninterrupted power support at critical moments.
Diagnostic and monitoring functions:
The 8310 power module is equipped with diagnostic function, which can monitor the power status and system operation status in real time. Once a power failure or voltage abnormality occurs, the module will promptly report it through the system's diagnostic function, making it convenient for maintenance personnel to troubleshoot.
Support online monitoring and remote access, facilitating system maintenance and troubleshooting for operation and maintenance personnel without interrupting production.
Compact and modular design:
Modular design makes installation and maintenance more convenient, and users can easily add or replace power modules as needed.
Compact design helps save rack space and is suitable for occasions that require high-density installation.
2.產 品 展 示
