HIMA F3226A輸入模塊 PDF資料
1.產 品 資 料 介 紹：
中文資料：
HIMA F3226A 輸入模塊 是 HIMA 公司生產的一款用于 安全控制系統 的輸入模塊，屬于其 HIMax 系列控制系統的一部分，主要用于安全相關的自動化應用。
主要特點：
高安全性：
- F3226A 輸入模塊符合 SIL 3 安全完整性等級，適用于關鍵的安全應用，如化工、石油天然氣、電力等行業。
- 模塊能夠有效處理危險環境中的信號，確保系統的穩定和安全。
多種輸入信號支持：
- 支持 數字輸入（DI）信號，適用于開關量傳感器、按鈕、繼電器等輸入設備。
- 提供冗余設計，確保在系統故障時仍能保持功能。
高可靠性：
- 設計符合工業標準，能夠在惡劣的環境條件下可靠運行。
- 具備抗干擾能力，能夠應對電氣噪聲、振動等影響。
模塊化與擴展性：
- F3226A 輸入模塊可與 HIMA HIMax 系統中的其他模塊一起使用，支持系統擴展和靈活配置。
- 具有 熱插拔 功能，可以在不中斷系統運行的情況下進行更換或維護。
診斷和監控功能：
- 內置 自診斷功能，能夠?qū)崟r(shí)監控模塊狀態，發現故障時自動報警，確保系統穩定運行。
- 提供詳細的故障信息，幫助維護人員快速定位問題。
應用領域：
- 化工和石油天然氣行業： 用于過程控制和安全儀表系統中，監控關鍵設備和操作。
- 電力和能源管理： 在發電廠和電力設施中，確保安全監控和緊急停機系統的可靠性。
- 自動化控制系統： 用于工業自動化系統中的安全監控和輸入信號處理。
技術規格：
| 參數 | 說明 |
|---|---|
| 輸入類型 | 數字輸入（DI） |
| 安全等級 | SIL 3 |
| 模塊類型 | 輸入模塊 |
| 冗余設計 | 支持冗余 |
| 工作溫度范圍 | -20°C 至 +60°C |
| 電源要求 | 24V DC |
| 診斷功能 | 支持自診斷與故障報警 |
優點：
- 高度集成與冗余設計確保系統在故障時仍能安全運行。
- SIL 3 認證符合嚴格的安全標準，適用于高風險的工業應用。
- 提供實時故障監控和診斷，簡化維護和故障排查工作。
英文資料：
The HIMA F3226A input module is an input module produced by HIMA for safety control systems, which is part of their HIMax series control systems and is mainly used for safety related automation applications.
Main features:
High security:
The F3226A input module complies with SIL 3 safety integrity level and is suitable for critical safety applications such as chemical, oil and gas, power and other industries.
The module can effectively process signals in hazardous environments, ensuring the stability and safety of the system.
Multiple input signals support:
Supports digital input (DI) signals, suitable for input devices such as switch sensors, buttons, relays, etc.
Provide redundant design to ensure functionality is maintained in the event of system failure.
High reliability:
Designed to meet industry standards and capable of reliable operation in harsh environmental conditions.
Capable of anti-interference ability, able to cope with electrical noise, vibration and other impacts.
Modularity and Scalability:
The F3226A input module can be used together with other modules in the HIMA HIMax system, supporting system expansion and flexible configuration.
It has hot swappable function and can be replaced or maintained without interrupting system operation.
Diagnostic and monitoring functions:
Built in self diagnostic function, capable of real-time monitoring of module status, automatically alerting when faults are detected, ensuring stable system operation.
Provide detailed fault information to help maintenance personnel quickly locate the problem.
Application areas:
Chemical and oil and gas industries: used in process control and safety instrumented systems to monitor critical equipment and operations.
Electricity and energy management: Ensure the reliability of safety monitoring and emergency shutdown systems in power plants and facilities.
Automation control system: used for safety monitoring and input signal processing in industrial automation systems.
Technical specifications:
Parameter Description
Input Type: Digital Input (DI)
Safety level SIL 3
Module Type Input Module
Redundant design supports redundancy
Working temperature range -20 ° C to+60 ° C
Power requirement 24V DC
Diagnostic function supports self diagnosis and fault alarm
advantage:
Highly integrated and redundant design ensures that the system can still operate safely in the event of a failure.
SIL 3 certification complies with strict safety standards and is suitable for high-risk industrial applications.
Provide real-time fault monitoring and diagnosis, simplify maintenance and troubleshooting work.
2.產 品 展 示
