EATON-MOELLER XV-363-10-C02-A00-1B 觸摸屏 PDF資料
1.產 品 資 料 介 紹：
中文資料：
EATON-MOELLER XV-363-10-C02-A00-1B 觸摸屏 是由 Eaton（伊頓）和 Moeller（莫勒）聯合生產的一款工業控制面板觸摸屏。它被廣泛應用于自動化控制、過程監控和數據可視化系統中，為操作人員提供直觀、易于操作的界面。
主要特點：
高分辨率觸摸屏：
- XV-363-10-C02-A00-1B 配備了高分辨率的觸摸顯示屏，能夠清晰顯示各種數據和圖形界面，提升用戶體驗。
- 支持 TFT LCD 屏幕，顯示效果細膩，適合長時間顯示監控?cái)?shù)據。
多功能顯示與控制：
- 可以顯示實時過程數據、系統狀態和報警信息。
- 支持 觸摸操作，用戶可以直接通過觸摸屏進行操作、參數調整和系統控制，簡化了用戶交互方式。
強大的通信接口：
- 支持多種工業通信協議，如 Modbus RTU/TCP、CANopen、Profibus 等，能夠與各種控制設備和自動化系統（如 PLC、DCS 等）無縫連接，確保數據傳輸?shù)姆€(wěn)定性和實時性。
靈活的界面定制：
- 用戶可以根據需求進行界面設計和定制，支持圖標、按鈕、曲線圖等多種元素的自定義，適應不同的應用場景。
- 配合Eaton的 Xsoft-CoDeSys 或其他編程工具進行圖形界面開發，滿足復雜的監控需求。
高可靠性和耐用性：
- 該觸摸屏具有 工業級耐用性，可以在惡劣環境下穩定工作，包括較高的溫度、濕度和電磁干擾。
- 采用 堅固的外殼，防塵、防水、抗振動，適合工廠車間等工業環境。
操作簡便：
- 觸摸屏操作直觀簡便，配合定制的圖形用戶界面（GUI），使得操作員可以快速了解系統狀態，進行必要的控制和調整。
- 觸摸響應靈敏，減少了傳統按鈕操作的復雜性。
應用領域：
- 工業自動化控制： 用于監控和控制生產線、機械設備、自動化裝置等。
- 過程監控： 在化工、食品飲料、電力等領域的生產過程監控中，提供實時數據展示和報警控制。
- 樓宇自動化： 用于建筑管理系統（BMS），包括空調、照明、安全監控等系統的控制。
- 機械設備控制： 可用于各種機械設備的操作面板，提供實時的狀態信息和控制接口。
技術規格：
| 參數 | 說明 |
|---|---|
| 顯示類型 | 觸摸式TFT LCD顯示屏 |
| 分辨率 | 320 x 240（可能視具體型號而定） |
| 觸摸方式 | 電阻式觸摸或電容式觸摸（具體依型號而定） |
| 通信接口 | Modbus RTU/TCP, CANopen, Profibus 等 |
| 輸入電壓 | 24V DC（典型） |
| 操作溫度范圍 | -10°C 至 +60°C |
| 安裝方式 | 面板安裝或嵌入式安裝 |
| 尺寸 | 根據具體型號尺寸而定（通常為 3.5 英寸到 12 英寸） |
| 防護等級 | IP65（前面板防水防塵） |
| 外殼材料 | 耐用塑料或金屬外殼，具備抗電磁干擾能力 |
英文資料：
The EATON-MOELLER XV-363-10-C02-A00-1B touch screen is an industrial control panel touch screen jointly produced by Eaton and Moeller. It is widely used in automation control, process monitoring, and data visualization systems, providing operators with an intuitive and easy-to-use interface.
Main features:
High resolution touch screen:
XV-363-10-C02-A00-1B is equipped with a high-resolution touch screen display, which can clearly display various data and graphical interfaces, enhancing the user experience.
Supports TFT LCD screen with delicate display effect, suitable for long-term display of monitoring data.
Multi functional display and control:
It can display real-time process data, system status, and alarm information.
Support touch operation, users can directly operate, adjust parameters, and control the system through the touch screen, simplifying user interaction.
Powerful communication interface:
Supporting multiple industrial communication protocols such as Modbus RTU/TCP, CANopen, Profibus, etc., it can seamlessly connect with various control devices and automation systems (such as PLC, DCS, etc.), ensuring the stability and real-time performance of data transmission.
Flexible interface customization:
Users can design and customize the interface according to their needs, supporting customization of various elements such as icons, buttons, and curve graphs to adapt to different application scenarios.
Collaborate with Eaton's Xsoft CodeSys or other programming tools for graphical interface development to meet complex monitoring requirements.
High reliability and durability:
This touch screen has industrial grade durability and can work stably in harsh environments, including high temperatures, humidity, and electromagnetic interference.
Adopting a sturdy shell, dustproof, waterproof, and vibration resistant, suitable for industrial environments such as factory workshops.
Easy to operate:
The touch screen operation is intuitive and simple, coupled with a customized graphical user interface (GUI), allowing operators to quickly understand the system status and make necessary controls and adjustments.
The touch response is sensitive, reducing the complexity of traditional button operations.
Application areas:
Industrial automation control: used for monitoring and controlling production lines, mechanical equipment, automation devices, etc.
Process monitoring: Provide real-time data display and alarm control in the production process monitoring of chemical, food and beverage, power and other fields.
Building automation: used for controlling building management systems (BMS), including air conditioning, lighting, safety monitoring, and other systems.
Mechanical equipment control: It can be used as an operation panel for various mechanical equipment, providing real-time status information and control interfaces.
Technical specifications:
Parameter Description
Display type: Touch sensitive TFT LCD display screen
Resolution 320 x 240 (may vary depending on specific model)
Touch method: resistive touch or capacitive touch (depending on the model)
Communication interfaces such as Modbus RTU/TCP, CANopen, Profibus, etc
Input voltage 24V DC (typical)
Operating temperature range -10 ° C to+60 ° C
Installation method: panel installation or embedded installation
The size depends on the specific model size (usually 3.5 inches to 12 inches)
Protection level IP65 (front panel waterproof and dustproof)
Durable plastic or metal shell material with anti electromagnetic interference capability
