Woodward 8290-185速度控制器 PDF資料
1.產 品 資 料 介 紹：
中文資料：
Woodward 8290-185 速度控制器 是 Woodward 公司生產的一款用于 發動機和渦輪機的數字式速度控制器。它主要應用于發電機組、工業發動機以及其他需要精確速度控制的機械設備中，廣泛用于電力、船舶、石油天然氣等行業。
主要特點：
精準的速度控制：
- Woodward 8290-185 提供 數字化速度控制，能夠精確調整和穩定機械設備的轉速，確保發動機或渦輪的高效運行。
- 控制精度高，能滿足各種工業應用中對速度的嚴格要求。
靈活的輸入和輸出：
- 支持多種輸入信號，包括 模擬信號（如 4-20 mA, 0-10 V）和 頻率輸入，使得它能夠與多種不同類型的發動機和驅動系統兼容。
- 提供 模擬輸出 和 數字輸出，方便與外部監控系統或其他控制系統連接。
多功能控制：
- 除了基礎的轉速控制外，8290-185 還可以進行 負載調節，提供 加速/減速控制、負載共享等功能，優化設備性能。
- 支持 穩速控制、分布式控制等高級功能，提高系統整體的穩定性和效率。
靈活的設置和調節：
- 用戶可以通過 前面板設置 或 遠程控制 進行參數調整。
- 配備有 液晶顯示屏，顯示操作狀態、設定值、診斷信息等，便于實時監控和調節。
可靠性與耐用性：
- 設計符合工業標準，適用于惡劣的環境條件，能夠在高溫、高濕和振動的情況下穩定運行。
- 擁有 防護等級，確保設備在工業環境中長期穩定工作。
通信與集成能力：
- 支持多種工業通信協議，如 Modbus RTU、CANopen，便于與現有的自動化系統進行集成。
- 可以通過 遠程操作 和 診斷 功能提高系統的管理效率。
自診斷和故障檢測：
- 內置自診斷功能，可實時監測系統狀態，發現異常時自動報警。
- 提供詳細的故障信息，幫助維護人員快速定位并解決問題。
應用領域：
- 發電行業： 用于燃?xì)廨啓C(jī)、柴油發電機組等設備的轉速控制。
- 船舶領域： 監控和調節船舶發動機的轉速，確保航行中的穩定性和安全性。
- 石油天然氣行業： 用于油氣田開發和生產過程中的動力設備控制。
- 工業自動化： 控制工業發動機和驅動系統，廣泛應用于各種機械設備、輸送帶系統等。
- 風力發電： 用于風電機組的轉速控制，確保發電機組在不同風速下穩定運行。
技術規格：
| 參數 | 說明 |
|---|---|
| 控制類型 | 數字式速度控制器 |
| 輸入信號 | 模擬信號（4-20 mA, 0-10 V）、頻率輸入 |
| 輸出信號 | 模擬輸出、數字輸出 |
| 通信協議 | Modbus RTU、CANopen |
| 控制精度 | 高精度速度控制，響應迅速 |
| 電源要求 | 24V DC 或 48V DC |
| 工作溫度范圍 | -40°C 至 +70°C |
| 防護等級 | IP20（適合機柜或控制面板內安裝） |
| 尺寸 | 根據具體型號而定 |
| 顯示方式 | 液晶顯示屏，提供實時狀態監控和診斷功能 |
優點：
- 精確控制：提供精確的速度控制和負載調節，優化設備的運行效率。
- 多功能支持：支持多種輸入輸出方式，適應不同應用需求。
- 可靠性：設計耐用，適應惡劣工業環境，長期穩定運行。
- 易于集成：支持多種通信協議，易于與其他控制系統集成。
- 自診斷功能：實時監控設備狀態，確保系統的安全性和穩定性。
英文資料：
The Woodward 8290-185 speed controller is a digital speed controller produced by Woodward for engines and turbines. It is mainly used in generator sets, industrial engines, and other mechanical equipment that require precise speed control, and is widely used in industries such as electricity, ships, oil and gas.
Main features:
Accurate speed control:
Woodward 8290-185 provides digital speed control that can accurately adjust and stabilize the speed of mechanical equipment, ensuring efficient operation of engines or turbines.
High control accuracy, able to meet the strict speed requirements in various industrial applications.
Flexible input and output:
Supports multiple input signals, including analog signals (such as 4-20 mA, 0-10 V) and frequency inputs, making it compatible with various types of engines and drive systems.
Provide analog and digital outputs for easy connection with external monitoring systems or other control systems.
Multi functional control:
In addition to basic speed control, the 8290-185 can also perform load regulation, provide acceleration/deceleration control, load sharing, and other functions to optimize equipment performance.
Support advanced functions such as stable speed control and distributed control to improve the overall stability and efficiency of the system.
Flexible settings and adjustments:
Users can adjust parameters through the front panel settings or remote control.
Equipped with an LCD display screen, it displays operational status, set values, diagnostic information, etc., making it easy to monitor and adjust in real time.
Reliability and Durability:
Designed to meet industrial standards, suitable for harsh environmental conditions, and capable of stable operation under high temperature, high humidity, and vibration conditions.
Having a protection level to ensure long-term stable operation of equipment in industrial environments.
Communication and integration capabilities:
Supports multiple industrial communication protocols, such as Modbus RTU and CANopen, for easy integration with existing automation systems.
The management efficiency of the system can be improved through remote operation and diagnostic functions.
Self diagnosis and fault detection:
Built in self diagnostic function, which can monitor the system status in real time and automatically alarm when abnormalities are detected.
Provide detailed fault information to assist maintenance personnel in quickly locating and resolving issues.
Application areas:
Power generation industry: used for speed control of equipment such as gas turbines and diesel generators.
Ship field: Monitor and adjust the speed of ship engines to ensure stability and safety during navigation.
Oil and gas industry: used for power equipment control in oil and gas field development and production processes.
Industrial automation: controls industrial engines and drive systems, widely used in various mechanical equipment, conveyor belt systems, etc.
Wind power generation: used for speed control of wind turbines to ensure stable operation at different wind speeds.
Technical specifications:
Parameter Description
Control type: digital speed controller
Input signal analog signal (4-20 mA, 0-10 V), frequency input
Output signal analog output, digital output
Communication protocols Modbus RTU, CANopen
High precision speed control with quick response
Power requirement 24V DC or 48V DC
Working temperature range -40 ° C to+70 ° C
Protection level IP20 (suitable for installation in cabinets or control panels)
The size depends on the specific model
Display mode: LCD screen, providing real-time status monitoring and diagnostic functions
advantage:
Precise Control: Provides precise speed control and load regulation to optimize the operational efficiency of the equipment.
Multi functional support: Supports multiple input and output methods to meet different application needs.
Reliability: Designed to be durable, adaptable to harsh industrial environments, and capable of long-term stable operation.
Easy to integrate: Supports multiple communication protocols and is easy to integrate with other control systems.
Self diagnostic function: Real time monitoring of device status to ensure system safety and stability.
2.產 品 展 示
