TRICONEX 2000418數字輸出模塊 PDF資料
1.產 品 資 料 介 紹：
中文資料：
TRICONEX 2000418 數字輸出模塊 是 Triconex 系列控制系統中的一個重要組件，專門用于將控制系統中的數字信號輸出到外部設備（如閥門、繼電器、報警器等）。以下是該模塊的簡要特點和應用：
主要特點：
- 數字輸出支持：將系統的數字控制信號（如開/關、啟停等）輸出到執行器或外部設備。
- 高冗余設計：與 Triconex 系統的 三重冗余（TMR） 配置兼容，即使部分模塊發生故障，系統仍能保持穩定運行。
- 高安全性：符合 SIL3 安全標準，適用于對安全性要求極高的關鍵系統。
- 模塊化設計：支持熱插拔功能，便于進行模塊更換和維護，減少停機時間。
- 多個輸出通道：提供多個數字輸出通道，可同時控制多個設備，提升系統的靈活性和擴展性。
- 高可靠性：設計用于高要求、長時間穩定運行的工業環境，確保控制信號的準確性和穩定性。
應用領域：
- 安全儀表系統（SIS）：執行緊急停機、報警或其他安全控制任務。
- 過程控制系統：用于控制工業設備（如閥門、泵、電機等）的開關狀態，確保生產過程的順利進行。
- 自動化控制：在自動化系統中執行各種數字控制任務，常見于石油、天然氣、化工等行業。
優勢：
- 高可靠性和冗余設計，確保關鍵過程和安全控制的穩定運行。
- 靈活擴展，可以通過多個輸出通道同時控制多個設備，滿足復雜的工業控制需求。
- 易于維護和更換，熱插拔設計大大減少了系統停機時間，提升了維護效率。
TRICONEX 2000418 數字輸出模塊 適用于要求高可靠性、高冗余的安全儀表系統（SIS）和自動化控制系統，確保外部設備能夠精確執行控制系統下達的操作命令。
英文資料：
The Triconex 2000418 digital output module is an important component in the Triconex series control system, specifically designed to output digital signals from the control system to external devices such as valves, relays, alarms, etc. The following are the brief features and applications of this module:
Main features:
Digital output support: Output the system's digital control signals (such as on/off, start stop, etc.) to actuators or external devices.
High redundancy design: Compatible with the Triple Redundancy (TMR) configuration of the Triconex system, the system can maintain stable operation even if some modules fail.
High security: Compliant with SIL3 security standards, suitable for critical systems with extremely high security requirements.
Modular design: supports hot swappable function, facilitates module replacement and maintenance, and reduces downtime.
Multiple output channels: Provides multiple digital output channels that can control multiple devices simultaneously, enhancing the flexibility and scalability of the system.
High reliability: designed for industrial environments with high requirements and long-term stable operation, ensuring the accuracy and stability of control signals.
Application areas:
Safety Instrumented System (SIS): performs emergency shutdown, alarm, or other safety control tasks.
Process control system: used to control the on/off status of industrial equipment (such as valves, pumps, motors, etc.) to ensure the smooth progress of the production process.
Automated control: Performing various digital control tasks in automated systems, commonly found in industries such as petroleum, natural gas, and chemical.
Advantages:
High reliability and redundancy design ensure stable operation of critical processes and safety controls.
Flexible expansion allows for simultaneous control of multiple devices through multiple output channels, meeting complex industrial control requirements.
Easy to maintain and replace, the hot swappable design greatly reduces system downtime and improves maintenance efficiency.
The TRICONEX 2000418 digital output module is suitable for safety instrumented systems (SIS) and automation control systems that require high reliability and redundancy, ensuring that external devices can accurately execute the operation commands issued by the control system.
2.產 品 展 示
